DP 2016/14 - Attachment 8. DP2.2 – First to Fourth Floor Plan

January 10, 2017Page 671 section

Typical residential floor plans for levels one through four of the North Building.

2. APPROVAL OF AGENDA
15 units per floor

Eagle Creek Village Phase 2 - North Bldg

NORTH BUILDING FIRST TO FOURTH FLOOR PLAN

Architectural floor plan for the first to fourth floors of the North Building, detailed with unit types A, B, Ci, D, and E, including balconies, corridors, elevators, and stairs.
Architectural floor plan for the first to fourth floors of the North Building, detailed with unit types A, B, Ci, D, and E, including balconies, corridors, elevators, and stairs.

FIRST TO FOURTH FLOOR PLAN DATA

Unit Type Unit Count Area (m²) Area (SQ. FT)
UNIT A1 (1 UNIT) 62.2m² [670 SQ.FT]
UNIT C1i (1 UNIT) 77.4m² [833 SQ.FT]
UNIT A (4 UNITS) 55.3 x 4 = 221.2m² [2,380 SQ.FT]
UNIT B (1 UNIT) 80.7m² [868 SQ.FT]
UNIT Ci (4 UNITS) 76.3 x 4 = 305.2m² [3,285 SQ.FT]
UNIT D1i (1 UNIT) 87.2m² [939 SQ.FT]
UNIT D2i (1 UNIT) 87.2m² [939 SQ.FT]
UNIT D4i (1 UNIT) 89.7m² [966 SQ.FT]
UNIT E2i (1 UNIT) 96.8m² [1,042 SQ.FT]
  • TOTAL 15 UNITS PER FLOOR: 1107.6 m² [11,922 SQ.FT]
  • CORRIDOR / ELEVATOR AREA: 167.5m² [1,803 SQ.FT]
  • TOTAL AREA: 1350m² [14,531 SQ. FT] (TO EXTERIOR OF SHEATHING)

Project Information

  • Project Number: 11 14 032
  • Drawn: MB
  • Checked: IM
  • Drawing Number: DP2.2
  • Date: NOV 18, 2014 (Revision 1: ISSUED FOR DP)
