LARGE SCALE UNIT PLANS - DP2.6

Floor plans for Unit A, Unit A1, Unit B, Unit C1i, and Unit Ci at Eagle Creek Village Phase 2 - North Bldg
Floor plans for Unit A, Unit A1, Unit B, Unit C1i, and Unit Ci at Eagle Creek Village Phase 2 - North Bldg

Project Information

  • Project: Eagle Creek Village Phase 2 - North Bldg
  • Project Number: 11 14 032
  • Drawn By: RI
  • Checked By: IM
  • Date: NOV 16, 2016
  • Status: NOT FOR CONSTRUCTION

Unit Floor Plans

1 UNIT A

  • Master (King): 10'5" x 11'6"
  • Living/Dining: 12'4" x 16'8"
  • Kitchen: 12'5" x 8'2"
  • Bathroom: 8'2" x 5'2"
  • Features: W.I.C., Pantry Shelves
  • Balcony: 4000 x 2500

2 UNIT A1

  • Master (King): 10'5" x 11'6"
  • Living/Dining: 12'4" x 16'8"
  • Kitchen: 12'5" x 8'2"
  • Bathroom: 5'2" x 8'2"
  • Features: W.I.C., Pantry Shelves
  • Balcony: 13' x 5'

3 UNIT B

  • Master (King): 10' x 13'2"
  • Bedroom (Queen): 10'2" x 11'11"
  • Living/Dining: 12'7" x 15'11"
  • Kitchen: 8'4" x 9'8"
  • Bathroom: 8'2" x 5'2"
  • Features: W.I.C., Pantry Shelves, Storage
  • Balcony (King): 13' x 5'

4 UNIT C1i

  • Master (King): 10' x 12'
  • Living: 11' x 9'3"
  • Dining: 11'11" x 7'4"
  • Kitchen: 12'9" x 8'2"
  • Ensuite: 8'4" x 5'
  • Bathroom: 5' x 9'
  • Features: W.I.C.
  • Balcony: 10' x 7'

5 UNIT Ci

  • Master (King): 10' x 11'6"
  • Living: 11' x 9'3"
  • Dining: 11'11" x 7'4"
  • Kitchen: 12'9" x 8'2"
  • Ensuite: 8'4" x 5'
  • Bathroom: 5' x 5'2"
  • Features: W.I.C.
  • Balcony: 10' x 7'
Page 70–71

LARGE SCALE UNIT PLANS - DP2.7

Floor plans for Unit D1i, Unit D2i, Unit D4i, and Unit E2i at Eagle Creek Village Phase 2 - North Bldg
Floor plans for Unit D1i, Unit D2i, Unit D4i, and Unit E2i at Eagle Creek Village Phase 2 - North Bldg

Project Information

  • Project: Eagle Creek Village Phase 2 - North Bldg
  • Project Number: 11 14 032
  • Drawn By: RI
  • Checked By: IM
  • Date: NOV 16, 2016
  • Status: NOT FOR CONSTRUCTION

Unit Floor Plans

1 UNIT D1i

  • Master (King): 12' x 9'8"
  • Bedroom: 10' x 11'4"
  • Living: 11'10" x 12'4"
  • Dining: 8'8" x 12'4"
  • Kitchen: 10'7" x 9'2"
  • Features: Pantry Shelves, Storage
  • Balcony: 8' x 12'

2 UNIT D2i

  • Master (King): 14'2" x 9'8"
  • Bedroom: 12' x 9'3"
  • Living: 11'10" x 12'4"
  • Dining: 8'8" x 12'4"
  • Kitchen: 10'5" x 12'4"
  • Ensuite: 7'11" x 5'7"
  • Bathroom: 5' x 5'4"
  • Features: W.I.C., Pantry, Storage
  • Balcony: 8' x 12'

3 UNIT D4i

  • Master (King): 14'2" x 9'8"
  • Bedroom: 12' x 9'3"
  • Living: 11'10" x 12'4"
  • Dining: 8'8" x 12'4"
  • Kitchen: 10'5" x 12'4"
  • Ensuite: 7'11" x 5'
  • Bathroom: 5' x 5'4"
  • Features: W.I.C., Pantry, Storage
  • Balcony: 8' x 12'

4 UNIT E2i

  • Master: 11' x 9'7"
  • Bedroom: 9'8" x 14'6"
  • Living: 20'8" x 13'4"
  • Kitchen: 10'7" x 9'2"
  • Ensuite: 8' x 5'10"
  • Bathroom: 5' x 8'2"
  • Features: W.I.C., Storage
  • Balcony: 8' x 12'8"
