Detailed conceptual layout for the proposed multi-family development, including building locations and green space.

4 Five-storey buildings46 Townhomes56% of Site Area as Green Space

THETIS LAKE RESIDENTIAL

Project Overview

  • 4 Five-storey buildings with 260 units
  • 46 Townhomes
  • Site Area: 559,515 SF
  • Green Space: 313,484 SF (56% of Site Area)
Conceptual site plan diagram showing the layout of Buildings A, B, C, and D with underground parking, 13 townhome blocks, property setbacks, and proximity to the Trans-Canada Highway.
Conceptual site plan diagram showing the layout of Buildings A, B, C, and D with underground parking, 13 townhome blocks, property setbacks, and proximity to the Trans-Canada Highway.

Site Plan Details

Multifamily Buildings:

  • Building A: 70 UNITS | GRN FLR - 17,630.0 SF
  • Building B: 60 UNITS | GRN FLR - 22,311.6 SF
  • Building C: 70 UNITS | GRN FLR - 25,261.7 SF
  • Building D: 60 UNITS | GRN FLR - 22,217.0 SF

Townhome Blocks:

  • Blocks 1 through 13 (Totaling 46 units)

Gross Floor Area Summary

Gross Floor Area
Multifamily
Building A
Building B
Building C
Building D
Total Multifamily
Townhomes
Block 1
Block 2
Block 3
Block 4
Block 5
Block 6
Block 7
Block 8
Block 9
Block 10
Block 11
Block 12
Block 13
Total Townhomes
Grand Total

WENSLEY ARCHITECTURE LTD PROJECT: 17014

Note: Conceptual site plan

Page 50
