Attachment 3: Parkland Screening - K.D. Hartwig Landscape Design

Parkland Screening Landscape Design

K.D. Hartwig Landscape Design 1870 McKenzie Schedule C, Drawing 9

General Site Layout and Features

The landscape plan for 1870 McKenzie includes the following site elements:

• Property Boundaries: Marked with a "FENCE LINE".
• Infrastructure: A "POWER POLE" is located near the upper boundary.
• Easements: A "B.C. HYDRO EASEMENT ESTIMATED BETWEEN THE BROKEN LINES" runs diagonally across the property.
• Natural Features: A "NATURAL TREE LINE" is indicated, with an area designated for "NATURAL CLEARANCE IN THIS AREA".
• Site Markers: A central marker labeled "H" is shown within the property grounds.

Pathway and Access

• Park Connection: An arrow indicates the "PATHWAY TO CONTINUE UNDER RAILWAY TO BURNSIDE PARK".
• Hillside Path Construction: A note in the upper right section states: "NOTE: IN THIS AREA THE PATH IS TO BE CONSTRUCTED WITH THE NATURAL CONTOUR OF THE ROCKY HILLSIDE. ONLY ALL TREE WITHIN 1 FT. OF PATH OF THIS AREA; ARE TO BE REMOVED; ALL LOW HANGING BRANCHES ARE TO BE PRUNED TO CLEAR THE PATHWAY FOR EASY PASSAGE."

Landscape Maintenance and Development Notes

Additional notes for the development and maintenance of the area include:

• Seeding: "PLANT CLOVER GRASS SEED IN THIS CORNER AFTER THE VEHICLES HAVE BEEN REMOVED."
• Natural Preservation: "THIS AREA TO BE RETAINED IN ITS NATURAL STATE."
• Path Treatment: "THE EXISTING PATHS (PRIMARY) ARE TO BE COVERED WITH A LAYER OF WOOD CHIPS."
• Pruning: "LOW HANGING BRANCHES ALONG PATHS ARE TO BE PRUNED."
