Attachment 3: Plan of Proposed Trunk Sewer (Glentana Housing)

April 12, 2022Page 3231 section

Engineering drawing illustrating the plan for a proposed trunk sewer near Shoreline Middle School.

Shoreline Middle SchoolGlentana HousingDrawing 1181-SK 11Internal page reference 323 of 330

PLAN OF PROPOSED TRUNK SEWER

Engineering plan showing the proposed trunk sewer for the Glentana Housing development
Engineering plan showing the proposed trunk sewer for the Glentana Housing development
Map detail showing Portage Inlet and Craigflower Road
Map detail showing Portage Inlet and Craigflower Road
Map detail showing Shoreline Drive and Shoreline School
Map detail showing Shoreline Drive and Shoreline School
Map detail showing the location of the Craigflower Pumping Station (Existing CRD Facility)
Map detail showing the location of the Craigflower Pumping Station (Existing CRD Facility)

Notes

  1. Pumping Station to be constructed entirely at the cost of the developer & to the plans & specifications approved by Chief Engineer of the Regional District to any work being undertaken.
  2. Pedestrian Ramp over Craigflower Road.
  3. Pedestrian Underpass beneath E & N Railway.
  4. Highway & parkway improvements as req'd by Dept. of Highways.
Detail of project notes and the top portion of the title block
Detail of project notes and the top portion of the title block
Detail showing the location note for a pedestrian ramp and the top of the revision table
Detail showing the location note for a pedestrian ramp and the top of the revision table
  • Approx. location of Pedestrian Ramp over Craigflower Road (Ref. Dwg. 13 of Schedule B of LUC 7-76)

Legend

  • -W- Proposed Watermain
  • -S- Proposed Sanitary Sewer
  • -D- Proposed Drain
  • -W- Existing Watermain
  • Note: This plan was redrawn Sept 21, 1977
Detail of the utility legend and redrawing note
Detail of the utility legend and redrawing note

Project Information

Item Detail
Land Use Contract CRC Ref. No. 7-76 SCHEDULE D - Dwg. 11
Firm KER, PRIESTMAN & ASSOCIATES LTD.
Client ASKE CONSTRUCTION LTD.
Project GLENTANA HOUSING
Drawing Title PLAN OF PROPOSED TRUNK SEWER
Date SEPT. 21, 1977
Scale 1" = 50'
Drawing Number 1181 - SK 11

Revisions

Rev Date Description
A 4-10-77 Land Use Contract Dwg Revised
