Appendix
Attachment 3: Plan of Onsite Services (Glentana Housing)
April 12, 2022Page 3241 section
Engineering drawing detailing onsite services including storm drains, watermains, and hydro/telephone lines for the Glentana Road development.
Glentana RoadDrawing 1181-SK 12Internal page reference 324 of 330
Plan of On-Site Services: Glentana Housing
Project Information
- Project Name: Glentana Housing
- Developer: Aske Construction Ltd.
- Drawing Title: Plan of On-Site Services
- Consulting Engineers: Ker, Priestman & Associates Ltd.
- Contract: Land Use Contract
- Drawing Number: 1181-SK 12
- Date: March 1977
- Scale: 1" = 50'
Revision History
| Revision | Date | Description |
|---|---|---|
| D | 5-20-77 | Notes revised |
| C | 4-13-77 | Land use contract dwg. No. adds B |
| B | 1-24-77 | Redraw as requested by Mun. of Esquimalt |
| A | 21-3-77 | Rev. per Dept. |
Legend
- Storm Drain: Indicated by a dashed line with circles.
- Watermain: Indicated by a thick solid line.
- Sanitary Manhole: Indicated by a circle marked with 'S'.
- Hydro Pole: Indicated by a point symbol.
- Hydrant: Indicated by a specialized hydrant symbol.
- Cleanout: Indicated by a symbol marked with 'CO'.
Site Notes and Annotations
- Proposed Fire Access Route: Labeled along the western edge of the development.
- Sanitary Sewer Note: Connections to View Royal Sanitary Sewer to be constructed as part of this development contract.
- Railway Underpass Note: E & N Railway Underpass (For Details See Dwg. No. 14 Schedule B of LUC 7-75).
- Continuation Note: For Continuation see Dwg. No. 11 Sheet 10 of 12 LUC 7-75.
- Roads: The plan identifies Glentana Road and Admiral's Road.
Page 324
