Committee of the Whole/Documents/Attachment 5 - Renderings and Elevations

Appendix

Attachment 5 - Renderings and Elevations

July 12, 2022Pages 378–3831 section

Architectural renderings and floor plans showing the front view and interior layout of the proposed residential addition.

LIVING AREA: 1034 SQ FT (upper floor of addition)Attachment 5, Pages 1-6

Architectural Renderings and Elevations

Architectural rendering showing the front and side elevations of a modern residence with dark grey siding, a brown tiled roof, and a wooden deck with a staircase.

Perspective rendering of the house from an elevated angle, showing the multi-level roof structure, side windows, and the wooden deck overlooking a lawn area.

Perspective rendering of the rear of the house, featuring a brown wooden garage door, a side entrance door, and a lower-level deck area with dark wooden privacy fencing.

Side elevation drawing with architectural dimensions, showing interior floor-to-ceiling heights of 10'-6 3/16", 7'-5 9/16", 10', and 10'-6 5/8", and a total structure height of 23'-9 5/16".

Floor Plan Specifications

Living Area: 1034 SQ FT

Component and Window Identifiers:

4040FX
8040FX
8040TC
3068
4430FX
5068FX
10068FX
7768FX
11668FX
12068
7072FX
8863FX
7052FX
7080FX
UP (Stairway indicators)

Side elevation drawing showing the exterior wall with window placements and height dimensions matching the primary architectural specifications.

Page 378–383
