Committee of the Whole/Documents/Attachment 3 - Site Plan
Appendix

Attachment 3 - Site Plan

July 12, 2022Page 4001 section

A site plan illustrating the required setbacks and the location of the proposed pergola on the property.

2 APPROVAL OF AGENDA
2.1 m setback4.9 m and 6.64 m dimensions

Site Plan - Chilco Road

Site plan for Lot 3, located on Chilco Road and adjacent to a park. The plan shows a "dwelling under construction" and an "Existing Patio" with a "Proposed Pergola." Red dashed lines indicate "Required Setbacks." Dimension callouts for the proposed pergola include 2.1 m, 6.64 m, and a 4.9 m setback measurement.
Site plan for Lot 3, located on Chilco Road and adjacent to a park. The plan shows a "dwelling under construction" and an "Existing Patio" with a "Proposed Pergola." Red dashed lines indicate "Required Setbacks." Dimension callouts for the proposed pergola include 2.1 m, 6.64 m, and a 4.9 m setback measurement.

Plan Notes

  • s shown under construction
  • ure is situate with respect to nearby
  • document is prepared for the use of the
  • for inspection purposes only.
  • m of boundary or lot redefinition.
  • mprovements shown.

Development Components

  • Location: CHILCO ROAD
  • Lot Identification: 3 (adjacent to Lot 4, Lot 2, and PARK)
  • Primary Structure: dwelling under construction
  • Secondary Structures: Existing Patio and Proposed Pergola
  • Setback Indicators: Required Setbacks (marked by red dashed lines)

Dimensions

Feature/Location Dimension
Proposed Pergola Length 6.64 m
Proposed Pergola Width 2.1 m
Pergola Setback Depth 4.9 m
Lot Frontage (Chilco Road) 14.797
Lot Depth (Park side) 27.085
Lot Depth (Lot 2 side) 26.497
Lot Width (Rear/Lot 4 side) 14.785
Right of Way/Easement 2.00m wide

Other Measurements on Plan

  • 16.30
  • 9.44
  • 3.12
  • 5.25
  • 2.74
  • 6.00
  • 3.20
  • 3.22
  • 1.52
  • 3.30
  • 0.64
  • 1.52
  • 1.37
  • 3.19
  • 3.20
  • 2.74
  • 3.65
  • 3.18
  • 4.66 (SAW)
  • 4.51
Page 400
