Attachment C - SITE PLAN - 258 Helmcken Road

SITE PLAN - A101

Project Information

Project: 1938 Client: Jeffrey Segura Project Name: THE ROYALE Address: 258 Island Highway, Victoria, BC Project Status: AS-BUILT Drawing: SITE PLAN Scale: 1:100

Site Details

Legal Description: LOT 1, SECTION 96, ESQUIMALT DISTRICT, PLAN 25529 Civic Address: 258 Island Highway, Victoria, BC Zoning: C4 (Commercial) Developer: DVP Corporation

Subject Site: PROPOSED 6 STOREY COMMERCIAL & MULTI-FAMILY RESIDENTIAL BUILDING.

Landscape Symbols & Removal Legend

EXISTING TREES TO BE REMOVED
EXISTING TREES TO BE RETAINED

General Notes

REFER TO LANDSCAPE DRAWINGS FOR DETAILED SITE LANDSCAPE DESIGN.

Plan Features

The site plan details the building layout at the intersection of Helmcken Rd. and Island Hwy. Key features labeled include:

Primary Residential Entrance & Residential Entrance
Ramp to Parking
Car from CRU (Commercial Rental Unit)
Sidewalks along both road frontages
Proposed and existing trees
Access to Commercial Parking

Submission History

Date	Description
2020-04-17	Issued for Rezoning
2021-08-31	Issued for Rezoning
2021-09-08	Issued for DP
2021-12-08	Revised for DP
2022-01-20	Revised for DP
2022-06-15	Revised for DP
2023-01-24	Revised for DP
2023-03-31	Issued for Construction
2024-04-15	As-Built

Revision History

No.	Date	Description
1	2024-04-15	As-Built

Architect Information

ANKENMAN MARCHAND ARCHITECTS Suite 203 - 1055 West Broadway Vancouver, BC V6H 1E2 Tel: (604) 872-2594 Email: office@amarchitects.com
