GROUND FLOOR PLAN

Project: 1938 Client: Jeffrey Sanipers Project Name: THE ROYALE Address: 254 Island Highway Rd, Victoria, BC Drawing: GROUND FLOOR PLAN Project Status: AS-BUILT Architects: ANKENMAN MARCHAND ARCHITECTS Drawing No: A110 Scale: As indicated

Submission Schedule

Date	Description
2021-08-31	Issued for Rezoning
2022-05-27	Issued for Rezoning Rev.
2023-01-20	Issued for DP
2023-11-20	Issued for DP Rev.
2024-04-12	Issued for BP
2024-05-13	Issued for BP
2024-05-30	Issued for BP
2024-06-12	Issued for Construction
2024-06-28	As-Built

Revision Schedule

No.	Date	Description
1	2024-08-27	Resubmittal per BI
2	2024-09-24	Resubmittal per BI

Drawing Legends

Line Type

OUTLINE OF BUILDING ABOVE
OUTLINE OF BALCONIES ABOVE
OUTLINE OF BUILDING BELOW
PROPERTY LINE
SETBACK
SWALE
SLAB OUTLINE
CONCRETE STRUCTURE BELOW

Legend Symbols

CONCRETE WALL
EXTERIOR STUD WALL
INTERIOR PARTITION
RAILING
PLANTER / SHRUB
WINDOW TAG
DOOR TAG
EXTERIOR WALL TAG
FINISH TAG
FIRE RATING
DIRECTION OF SLOPE
DRAIN / SUMP / CLEANOUT
CATCH BASIN / GRATE
FIRE HYDRANT
ELEVATION OF TOP OF CURB
ELEVATION OF FINISHED GRADE

General Notes

All drawings in this set to be read in conjunction with each other, any errors or discrepancies to be reported to the Architect prior to construction. It is the responsibility of the Contractor to ensure that all work is executed to the satisfaction of local authorities and with all applicable codes and bylaws.
