A technical site plan and survey showing the approximate parking area to be accessed via the Hospital Way gate.

1 CALL TO ORDER
2 Hospital WayParcel A (DD 137075-I), Block 1, Section 100, Esquimalt District, Plan 1066

Appendix A

BC LAND SURVEYORS SITE PLAN OF

Site plan text block for Civic: 2 Hospital Way, Parcel A (DD 137075-I), Block 1, Section 100, Esquimalt District, Plan 1066, except part in Plans 43365, VIP62916 and VIP62917
Site plan text block for Civic: 2 Hospital Way, Parcel A (DD 137075-I), Block 1, Section 100, Esquimalt District, Plan 1066, except part in Plans 43365, VIP62916 and VIP62917

Parcel identifier: 003-312-833 Prepared for: Associated Building Credits LTD SCALE 1 : 1250 (11x17 sheet) All distances are shown in metres.

Aerial survey map of the subject property showing the highlighted parking area and access point
Aerial survey map of the subject property showing the highlighted parking area and access point
  • Approximate Parking area – highlighted and cross hatched
  • Parking area to be accessed only via Hospital Way gate area
