Floor Plan - Craigflower Hall

March 5, 2019Page 261 section

Architectural floor plan for Craigflower Hall, detailing the layout for an event hall, lobby, patio, and support spaces.

1. CALL TO ORDER
January 4, 2019Craigflower Hall

Craigflower Hall - Victoria Scottish Community Centre

Floor Plan

Architectural floor plan of Craigflower Hall showing a circular central Event Hall surrounded by radial service rooms, including meeting rooms, an office, a green room, servery, storage, lounge, bar, and entrance lobbies. The plan also details outdoor patios, parking areas, and site boundaries near Island Highway.
Architectural floor plan of Craigflower Hall showing a circular central Event Hall surrounded by radial service rooms, including meeting rooms, an office, a green room, servery, storage, lounge, bar, and entrance lobbies. The plan also details outdoor patios, parking areas, and site boundaries near Island Highway.

General Notes

  1. General information, dimensions, and specifications on this drawing are subject to confirmation and are not to be used as part of the contract documents.

Revision History

rev no description date
2 Revised Rezoning App. 19/01/04
1 Rezoning Application 18/08/13

Project Information

  • Project Name: Craigflower Hall - Victoria Scottish Community Centre
  • Sheet Title: Floor Plan
  • Project No.: 1805
  • Date: January 4, 2019
  • Scale: 1:100
  • Drawn by: MJ
  • Checked by: FDA / ES
  • Sheet No.: A2.1

Plan Areas and Annotations

  • Event Hall: 423m²
  • Outdoor Patio
  • Entrance Lobby (East): 4.3m x 4.0m
  • Coat Room
  • Patio: 6m x 7.8m
  • Bar
  • Lounge: 5.8m x 6m
  • Event Storage
  • Loading / Receiving
  • Screened Refuse Area
  • Servery: 2.9m x 3.6m
  • Green Room: 4.2m x 3.6m
  • Office: 4m x 3.8m
  • Meeting / Flex Room: 12m x 6.2m
  • Entrance Lobby (West): 3.6m x 6.5m
  • Washrooms (M)
  • Washrooms (F)
  • Storage: 3.5m x 6m
  • Corridor
  • Vest.
  • J. Closet
  • W/C
  • Bike Parking: (9 Class 1)
  • Paved Parking Area
  • Island Highway
  • Existing Stone Wall
  • Foot Path
  • Proposed 6000 Setback
Page 26
