Elevations North + East - Craigflower Hall

March 5, 2019Page 291 section

Architectural elevation drawings showing the north and east exterior views of the proposed community center.

1. CALL TO ORDER
September 13, 2018Craigflower Hall
Architectural renderings showing the North and East elevations of the Craigflower Hall project, including material callouts and elevation height measurements.
Architectural renderings showing the North and East elevations of the Craigflower Hall project, including material callouts and elevation height measurements.

General Notes

  1. General information, dimensions, and specifications on this drawing are subject to confirmation and are not to be used as part of the contract documents.

Materials Key

  1. PEBBLE BALLAST ON ROOF
  2. METAL FASCIA
  3. STONE CLADDING
  4. LOW-E GLAZING
  5. CAST CONCRETE LINTEL
  6. GLASS GUARDRAIL
  7. WOOD GLULAM STRUCTURE
  8. WOOD ENTRY DOORS

Revision History

rev no description date
1 Rezoning Application 18/09/13

Project Information

  • Project name: Craigflower Hall Victoria Scottish Community Centre
  • Sheet title: Elevations North + East
  • Project no: 1805
  • Date: September 13, 2018
  • Scale: 1:100
  • Drawn by: MJ
  • Checked by: FDA / ES
  • Sheet no: A3.2

Elevation Measurements

  • Main Roof (max): 14.8m
  • Main Roof (min): 12.60
  • Lower Roof: 10.85
  • Floor Level: 7.50
  • Avg. Grade: 7.22

Drawing Labels

  • 1 NORTH ELEVATION 1:100
  • 2 EAST ELEVATION 1:100
  • CRAIGFLOWER MANOR (referenced in East Elevation)
Page 29
