Site Section - Craigflower Hall

March 5, 2019Page 311 section

Architectural site section drawing showing the proposed development in relation to the existing manor and Admirals Road.

1. CALL TO ORDER
Project no. 1805Scale 1:175

Craigflower Hall

Victoria Scottish Community Centre

North-South site section architectural drawing showing the topographical relationship between the existing Craigflower Manor, the proposed new Event Hall with service area and outdoor patio, and Admirals Road.
North-South site section architectural drawing showing the topographical relationship between the existing Craigflower Manor, the proposed new Event Hall with service area and outdoor patio, and Admirals Road.

General Notes:

  1. General information, dimensions, and specifications on this drawing are subject to confirmation and are not to be used as part of the contract documents.

Drawing Information:

Project Name Craigflower Hall Victoria Scottish Community Centre
Sheet Title Site Section
Project No. 1805
Drawing File
Date
Scale 1:175
Drawn By MJ
Checked By FDA / ES
Sheet No. A4.2

Section Detail:

  • 2 SITE SECTION - NORTH SOUTH (Scale 1:175)

Drawing Annotations:

  • Existing Craigflower Manor Beyond
  • Outdoor Patio
  • Event Hall
  • Service Area
  • Loading / Receiving
  • Existing Cedar Fence
  • Admirals Road
  • Approximate Outline of Existing Building
  • Property Lines (indicated by red dashed lines)
  • Graphic Scale (0 to 10 Meters)
Page 31
