Attachment 3. Posting Plan of Lot 3, Block 12, Section 8

April 2, 2013Page 241 section

Official land survey plan for the property at 283 Kerwood Street.

1 CALL TO ORDER
Address: 283 Kerwood StreetPlan 1688

POSTING PLAN OF LOT 3, BLOCK 12, SECTION 8, ESQUIMALT DISTRICT, PLAN 1688, PURSUANT TO SECTION 68, LAND TITLE ACT.

BCGS 92B.043

SCALE 1:250. All distances are in metres.

The intended plot size of this plan is 560mm in width by 432mm in height (C Size) when plotted at a scale of 1:250.

LEGEND

  • Astronomic bearings were derived from Posting Plan VIP72843.
  • Denotes Standard Iron Post.
  • Denotes Lead Plug.
  • Denotes Non-Standard Post.
  • Rk. Denotes short Iron Post set in rock.

NOTE: This plan shows one or more witness posts which are not set on the true corner(s).

Survey map showing Lot 3, Block 12, adjacent lots including Amended Lot 4 and Amended Lot 5, Kerwood Avenue, Beaumont Avenue, and the shoreline of Esquimalt Harbour with various topographical markings and survey points.
Survey map showing Lot 3, Block 12, adjacent lots including Amended Lot 4 and Amended Lot 5, Kerwood Avenue, Beaumont Avenue, and the shoreline of Esquimalt Harbour with various topographical markings and survey points.

NOTE:

Existing buildings are not located. Geodetic elevations are based upon Control Monument 1R06-11.

LEGEND

  • Denotes Geodetic Elevation
  • Denotes Utility Pole
  • Denotes Sanitary Manhole
  • Denotes Drain Manhole
  • (W) Denotes Water Meter
  • X Denotes Mark Set

File: 0560-JK-36A
Archive: 36A-GB-PP

Island Land Surveying Ltd.
1-15 Cadillac Avenue
Victoria, B.C. V8Z 1T3
TEL 250.475.1515 fax 250.475.1516
www.islandsurveying.ca

This plan lies within the Capital Regional District.
