Attachment 7. Proposed Landscape Site Plan - Koi Dragon Enterprises Ltd.

April 2, 2013Page 292 sections

Landscape plan showing plant list and patio dimensions, later superseded.

1 CALL TO ORDER
Date: Feb 16, 2013Patio Area: 257.8 SQ'

PLANT LIST

TREES

Qty Code Botanical Name Common Name Size
1 AC ACER CIRCINATUM VINE MAPLE 1.5m
2 AM ARBUTUS XANDRACHNOIDES 'MARINA' STRAWBERRY TREE #7

SHRUBS

Qty Code Botanical Name Common Name Size
22 BS BUXUS SEMPERVIRENS COMMON BOXWOOD #5
10 CD COTONEASTER 'DAMMERI' BEAR BERRY #1
7 CT CAREX TESTACEA ORANGE SEDGE #1
5 DF BLECHNUM SPICANT DEER FERN #1
15 LH LAVANDULA ANGUSTIFOLIA 'HIDCOTE' ENGLISH LAVENDER #1
8 MA MAHONIA AQUIFOLIUM OREGON GRAPE #3
18 SF POLYSTICHUM MUNITUM SWORD FERN #1
Page 29

NOTES

  • ORIGINAL PATIO (DRAWING NOV 27/2012) = 259.7 SQ'
  • AMENDED PATIO (DRAWING FEB 16/2013) = 257.8 SQ'

SUPERCEDED see Attachment 13

Hand-drawn landscape site plan for a property at 283 Kerwood St. The diagram illustrates a proposed patio area featuring a gas fire pit, a clear topless glass safety railing, and retaining walls with specified heights (e.g., "TOP OF WALL 12.1M"). The plan details a staircase leading past "EXPOSED BEDROCK" and planting beds labeled with codes from the plant list (e.g., "22.BS.", "8 SF", "5 DF"). Additional annotations include locations for "OAK CLUMP" groups, boulder placement requirements to decrease exposed wall height to 2m, and various site measurements ranging from 3.1M to 10.2M.
Hand-drawn landscape site plan for a property at 283 Kerwood St. The diagram illustrates a proposed patio area featuring a gas fire pit, a clear topless glass safety railing, and retaining walls with specified heights (e.g., "TOP OF WALL 12.1M"). The plan details a staircase leading past "EXPOSED BEDROCK" and planting beds labeled with codes from the plant list (e.g., "22.BS.", "8 SF", "5 DF"). Additional annotations include locations for "OAK CLUMP" groups, boulder placement requirements to decrease exposed wall height to 2m, and various site measurements ranging from 3.1M to 10.2M.

Project Information

Field Details
Company Koi Dragon Enterprises Ltd.
Address 924 Mesher place, Victoria BC, V9A 6Z1
Phone 250-383-0285
Cell 250-704-8338
Scale 1:100
Date FEB 16 2013
Drawn by BL
Proposed landscape for GREG BURKE, 283 KERWOOD ST, VIEW ROYAL
