Attachment 10. West Side Elevation (Rendered)

April 2, 2013Page 371 section

Visual rendering of the west side elevation including proposed landscaping.

1 CALL TO ORDER

Side Elevation

Side elevation landscape drawing detailing a patio structure, glass railing, rock-faced retaining wall, and soil berm.
Side elevation landscape drawing detailing a patio structure, glass railing, rock-faced retaining wall, and soil berm.

Design Features and Dimensions

  • Horizontal Measurements:

    • Edge of Structure to Patio Edge: 5.10m
    • Patio Edge transition: 1.5m
    • Intermediate span: 2.25m
    • Final section: 1.0m
    • Total span: 9.85m

  • Vertical Elevations:

    • Top of railing: 12.1m
    • Patio surface: 11.5m (0.6m railing height)
    • Retaining wall drop: 2.0m
    • Upper berm grade: 9.5m
    • Lower berm grade: 9.0m
    • Lowest point (natural grade): 8.35m

  • Material and Landscaping Notes:

    • Clear topless glass railing with black powder coat posts.
    • 0.5m soil berm.
    • 0.6-0.9m boulders to follow natural grade.
    • Rock-faced construction on patio and retaining walls.

  • Project Information:

    • KDE 16/02/13
    • Scale: 3cm = 1m
