Attachment 4. Proposed Foundation Position - Lot 3

April 2, 2013Page 541 section

Survey plan showing the proposed foundation position for the structure.

1 CALL TO ORDER
Date: February 13, 2012

PROPOSED FOUNDATION POSITION UPON LOT 3, BLOCK 12, SECTION 8, ESQUIMALT DISTRICT, PLAN 1688.

SCALE=1:250. All distances are in metres.

NOTE: Building positioned as per client instructions. Building position must be confirmed by approving authorities prior to construction.

Lot 3 is subject to Easement FB219569

This Plan lies within the Capital Regional District.

Survey Information Zoning & Set-backs
File: 36A-GB-LO Zoning: R1
Date: February 13, 2012 Minimum Set-backs
Island Land Surveying Ltd. Front: 7.5
1-115 Cadillac Avenue Rear: 15.0
Victoria, B.C. V8Z 1T3 Interior side: 2.14
Tel 250.475.1515 Fax 250.475.1516 Total side: 6.10
info@islandsurveying.ca

LEGEND

  • Denotes paint mark painted February 13, 2012

#.# Denotes ground elevation at paint mark

Detailed site plan for Lot 3, showing the proposed building foundation footprint, property boundaries adjacent to Kerwood Avenue and Esquimalt Harbour, setbacks from neighboring Lot 4 and Lot 2A, easement details, and various site features including trees (Oak, Maple, Fir), wood stakes, and a deck.
Detailed site plan for Lot 3, showing the proposed building foundation footprint, property boundaries adjacent to Kerwood Avenue and Esquimalt Harbour, setbacks from neighboring Lot 4 and Lot 2A, easement details, and various site features including trees (Oak, Maple, Fir), wood stakes, and a deck.

Site Plan Details

  • Location: Lot 3, Block 12, Section 8, Esquimalt District, Plan 1688.
  • Boundaries:
    • North: Kerwood Avenue (Edge and Pavement)
    • South: Esquimalt Harbour
    • West: AMENDED LOT 4
    • East: LOT 2A
  • Easement: Easement FB219569 Plan VIP85807 located along the western boundary.
  • Proposed Building: Footprint shown with various internal and setback dimensions.
  • Survey Features:
    • Nail in fence post (Elev=12.20m)
    • Various Oak clumps and Maple trees noted with diameters (e.g., 0.20 Oak, 0.40 Maple).
    • Wood stakes and rock (Rk.) indicators.
    • Existing deck shown at the southern end near the harbour.
  • North Arrow: Indicating orientation towards the harbour (South).
