Attachment 6. Staff Illustration of Variances

April 2, 2013Page 771 section

Annotated site plan highlighting the areas of proposed improvements and requested variances.

1 CALL TO ORDER

SITE PLAN OF STRATA LOT 7, STRATA PLAN 1301, SECTION 8, ESQUIMALT DISTRICT.

SCALE 1:300

  • ALL DISTANCES ARE IN METRES
  • LOT DIMENSIONS ARE DERIVED FROM REGISTERED PLANS AND NOT VERIFIED BY THIS SURVEY

CIVIC ADDRESS: # 7 GOVENORS POINT, 320 BESSBOROUGH AVENUE, VICTORIA, B.C.

Site plan of Strata Lot 7 showing the dwelling, deck, and common property access road. Annotations identify the area of rear stairs improvements, a 2.14m side yard setback, the area of front stairs patio improvements, and a 15m setback from the natural boundary.
Site plan of Strata Lot 7 showing the dwelling, deck, and common property access road. Annotations identify the area of rear stairs improvements, a 2.14m side yard setback, the area of front stairs patio improvements, and a 15m setback from the natural boundary.

Certification and Disclaimer

THIS DOCUMENT IS NOT VALID UNLESS ORIGINALLY SIGNED AND SEALED

THIS DOCUMENT IS FOR MORTGAGE PURPOSES ONLY AND NOT TO BE USED FOR THE RE-ESTABLISHMENT OF PROPERTY BOUNDARIES

I HEREBY CERTIFY THAT THE DWELLING SHOWN ON THE ABOVE LOT IS WHOLLY WITHIN THE BOUNDARIES THEREOF AND THAT THE SIDE, FRONT AND REAR YARDS ARE AS SHOWN AND NO BUILDINGS ENCROACH ONTO ADJOINING PROPERTY CERTIFIED CORRECT

OCTOBER 31, 1991

Surveyor Information

MICHAEL E. CLAXTON
B.C. LAND SURVEYOR
201-721 YANALMAN AVENUE
VICTORIA, B.C.
PHONE 478-2258 FAX 479-3831
FILE: 91 - 10536 - 36A
FB 194/97

Page 77
