Attachment 5. Existing Site - Plan A0.3

February 19, 2013Page 271 section

Site plan showing current conditions, including the existing house and site topography.

1 CALL TO ORDER
Oct 30, 20121:200 scale

Rezoning Development Permit Application

VIEW ROYAL TOWNHOUSE - Existing Site

Architectural site plan showing the existing conditions of a property, including boundaries for Lots 21, 22, 23, 24, and 25. The plan details existing building footprints, driveways, a garage, various elevation markers, and extensive vegetation mapping.
Architectural site plan showing the existing conditions of a property, including boundaries for Lots 21, 22, 23, 24, and 25. The plan details existing building footprints, driveways, a garage, various elevation markers, and extensive vegetation mapping.

Project Information

Field Value
Project number 211070
Date Oct/26/2012
Drawn by Xavier Crespo
Checked by Checker
Scale 1:200
Drawing Number A-0.3
