Council Meeting/Documents/Attachment 6. Site Plan - Plan A1.0
Appendix

Attachment 6. Site Plan - Plan A1.0

February 19, 2013Page 281 section

Detailed site plan showing building footprints, setbacks, and proposed driveway layout.

1 CALL TO ORDER
7 small car stallsFeb 05, 2013

Wayne Pye VIEW ROYAL TOWNHOUSE

Site Plan

Revised Site Plan with Subdivision for the View Royal Townhouse project at a scale of 1:200. The plan shows building footprints labeled A, B, and B1, an existing house, parking areas including '7 Small Car stalls', and road access from Old Island HWY and Plowright Rd. Dimensioned setbacks and property lines are indicated.
Revised Site Plan with Subdivision for the View Royal Townhouse project at a scale of 1:200. The plan shows building footprints labeled A, B, and B1, an existing house, parking areas including '7 Small Car stalls', and road access from Old Island HWY and Plowright Rd. Dimensioned setbacks and property lines are indicated.

Project Information

Field Detail
Project Number 211070
Date FEB/05/2013
Drawn by Xavier Crespo
Checked by Checker
Scale 1:200
Sheet Number A-1.0
Project Status Pre-Building Permit

Revisions

No. Date Description
4 Feb 05 2013 Transformer location / Setbacks
3 Oct-30-2012 DP Revision
2 April-30-2012 DP Revision
1 DEC-05-2011 DP Revision

Site Plan Details

  • Existing House: Located on lot area 531m2.
  • Buildings:
    • Buildings A: Two central structures, each showing a four-unit layout.
    • Building B: One row of four units along the northern property line.
    • Buildings B1: Several residential blocks located on the southern portion of the site (Lots 14, 15, 16, 23).
  • Parking: Includes "7 Small Car stalls 2.75m x 5.5m" and other standard stalls.
  • Infrastructure: Electrical Room, B-I-N-S area.
  • Road Access: Old Island HWY (north) and Plowright Rd (west).
  • Notes:
    • Refer to Landscape Plan.
    • PLAN 1238.
    • Specific setbacks and dimensions are provided throughout the plan (e.g., 3.00 m, 4.50 m, 6.00 m, 7.31 m, 8.28 m).
    • Drawing file reference: R:\Current_drawings\211070 View Royal Townhouses\Building Permit Submission\Rev4 Drawings\Site Plan rev transformer location.rvt
Page 28
Extracted from: 2013 02 19 Council Agenda
