Council Meeting/Documents/Attachment 8. Typical TH Floor Plans - Plan A1.2
Appendix

Attachment 8. Typical TH Floor Plans - Plan A1.2

February 19, 2013Page 301 section

Internal layouts for townhouse units Type A, B, and B1.

1 CALL TO ORDER
TH Type A 143.8m2TH Type B 148.0 m2Oct 30, 2012

Rezoning Development Permit Application

View Royal Townhouse

Typical TH Floor Plans

Architectural drawing sheet A-1.2 displaying nine detailed floor plans for three townhouse variations: TH Type A (143.8m2), TH Type B (148.0 m2), and TH Type B1 (148.0 m2). Each type is shown across three levels at a 1:100 scale, including interior layouts for garages, living areas, kitchens, and bedrooms.
Architectural drawing sheet A-1.2 displaying nine detailed floor plans for three townhouse variations: TH Type A (143.8m2), TH Type B (148.0 m2), and TH Type B1 (148.0 m2). Each type is shown across three levels at a 1:100 scale, including interior layouts for garages, living areas, kitchens, and bedrooms.

Architect Information Eric Barker Architect Inc. 717 Pandora Avenue, Victoria, B.C.

Project Data

Field Information
Project number 211076
Date Oct/30/2012
Drawn by Xavier Crespo
Checked by Checker
Scale 1:100
Sheet A-1.2

Revision History

No. Date Description
3 Oct-30-2012 DP Revision
2 Apr-30-2012 DP Revision
1 Sep-06-2011 DP Revision

Townhouse Type Floor Plans

TH Type A 143.8m2

  • (1) Level 1 Type A
  • (2) Level 2 Type A
  • (3) Level 3 Type A

TH Type B 148.0 m2

  • (4) Level 1 Type B
  • (5) Level 2 Type B
  • (6) Level 3 Type B

TH Type B1 148.0 m2

  • (7) Level 1 Type B1
  • (8) Level 2 Type B1
  • (9) Level 3 Type B1
Page 30
Extracted from: 2013 02 19 Council Agenda
