Attachment 10. Elevations / Sections - Plan A2.1

February 19, 2013Page 321 section

Additional elevation drawings showing different perspectives and side views of the townhouse blocks.

1 CALL TO ORDER

Oct 30, 2012

Rezoning Development Permit Application

VIEW ROYAL TOWNHOUSE

Attachment 10

Detailed architectural elevation drawings for a multi-unit townhouse project labeled Elevation 4 through Elevation 7, showing building facades, sloped topography, property lines, and material callouts.

Exterior Finishes

6" Exposure Shingles
2' Wide Vertical Board And Batten Hardie Panel
6" Exposure Horizontal Fiber Cement Siding
22 Ga Metal Fascia
Powder Coated Metal & Glass Railings
Natural Stone Low Wall

Certainteed Cedar Impressions® Double 9" Staggered Rough-Split Shakes and trim. Color: Terra Cotta
2' wide Fiber cement board and batten and trim
- Color 1: Benjamin Moore 2134-10 Night Horizon (LRV/PR 5.51)
- Color 2: Benjamin Moore HC-17 Summerdale Gold (LRV/PR 38.78)
6" exposure horizontal fiber cement plank siding and trim
- Color 1: Benjamin Moore HC-85 Fairview Taupe (LRV/PR 15.87)
- Color 2: Benjamin Moore HC-17 Summerdale Gold (LRV/PR 38.78)
Window trim and deck's fascia
- Color: Benjamin Moore 2095-10 Adirondack Brown (LRV/PR 8.28)

Revisions

No.	Date	Description
3	Oct-30-2012	DP Revision
2	Oct-18-2012	DP Revision
1	Sep-05-2012	DP Revision

Project Details

Project Name: VIEW ROYAL TOWNHOUSE
Drawing Title: Elevations/Sections
Project Number: 211070
Date: Oct/30/2012
Drawn By: Xavier Crespo
Checked By: Checker
Drawing Number: A-2.1
Scale: 1:200

Page 32
