Attachment 13. Phase 1 - Plan A5.0

February 19, 2013Page 351 section

Site phasing plan for the first stage of development construction.

1 CALL TO ORDER
8 temporary car stallsPhase 1 under construction

Rezoning Development Permit Application

VIEW ROYAL TOWNHOUSE

Phase 1

Site plan for Phase 1 of the View Royal Townhouse development, illustrating two blocks of townhouses under construction, temporary car stalls, and large hatched areas designating existing houses to remain undisturbed.
Site plan for Phase 1 of the View Royal Townhouse development, illustrating two blocks of townhouses under construction, temporary car stalls, and large hatched areas designating existing houses to remain undisturbed.

Revision History

No. Date Description
3 Oct-30-2012 DP Revision
2 April-02-2012 DP Revision
1 Sep-30-2011 DP Revision

Project Information

  • Project Number: 211078
  • Date: Oct/30/2012
  • Drawn by: Xavier Crispo
  • Checked by: Charlie
  • Scale: 1:200
  • Sheet Number: A-5.0

Plan Annotations

  • PHASE 1: Denotes the primary area of active development.
  • Phase 1 Under Construction: Indicates two building blocks, each containing four units labeled 'B'.
  • 8 Temporary Car stalls Under Construction: Located between the townhouse blocks, measuring 2.75m x 6.0m.
  • Denotes undisturbed area for phase 1: A large cross-hatched region surrounding the construction site.
  • Existing House Remains undisturbed: Noted in three separate locations within the hatched undisturbed area.
  • DRIVEWAY: Located at the bottom of the plan, providing access to the site.
