Attachment 5 Landscape Plan
February 1, 2022Page 401 section
Landscape concept plan for the Portage Park Residences project.
December 2, 2021Forsite Landscape Architecture
PORTAGE PARK RESIDENCES
LANDSCAPE CONCEPT PLAN
Project Information
- Property Name: Portage Park Residences
- Sheet Title: Landscape Concept Plan
- Sheet Number: L100
- Date: December 2, 2021
- Scale: 1:5000
- Drawn by: BF
Firm Information Forsite Landscape Architecture #408-1581H Hillside Ave. Victoria, BC V8T 2C1 Phone: 250.508.7885 Email: forsiteland@hotmail.com
Revision History
| REV. DATE | NUMBER | DESCRIPTION |
|---|---|---|
| 10-29-21 | 1 | PRELIMINARY PLAN FOR REVIEW |
| 12-02-21 | 1 | PRELIMINARY PLAN FOR REVIEW |
Softscape Legend
- Trees to be Retained: Indicated by a solid circle.
- Trees to be Removed: Indicated by a circle with an "X".
- Large Deciduous Shade Tree
- Small Ornamental Deciduous Trees
- Large and Small Coniferous Trees
- Large Shrub
- Medium Shrub
- Small Shrub
- Ground Cover & Perennials
Plan Features and Callouts
- PMT Location
- Ornamental Grasses
- Special Paved Parking Stall
- Sidewalk and Gate to Amenity Area
- Existing Trees in Grass Boulevard
- Sod Lawn
- Planted Rain Garden
- Class 2 Street Tree - Install "Deeproot" barrier adjacent to service line to protect infrastructure
- Extent of Deeproot Barrier
- Waterfall Fountain Feature at Entrance
- Boardwalk/Bridge
- Entrance Walkway
- Bench
- Bike Rack
- Quiet Patio w/ Stairs to Amenity Garden
- Grasses in Raised Concrete Planter
- Conifer Hedge
- Special Paved Patio
- Privacy Screen
- Concrete Walkway
- Planter w/ Tall Grasses
- Flower Tree in Round Pot
- Stepping Stones
- Social Pavilion c/w Tables, Chairs, BBQ, & Green Roof
- Indentation in Parking Garage for Tree Above
- Boardwalk/Bridge
- Patio with Bench
- Project Sign on Stone Sculpture Wall
- Walkway Connection to Park
- Split Rail Fencing
- Donation Trees for Park
- New Path Connection to Playground
- Strolling Path
- Native Plant Restoration for Park Edge Transition
- Large Deciduous Tree
Suggested Plant List
| Category | Botanical Name | Common Name |
|---|---|---|
| Deciduous Shade Trees | Acer rubrum 'Bowhall' | Bowhall Red Maple |
| Acer x freemanii 'Autumn Blaze' | Autumn Blaze Maple | |
| Carpinus betulus 'Fastigiata' | Columnar European Hornbeam | |
| Gleditsia triacanthos 'Skyline' | Skyline Honey Locust | |
| Liquidambar styraciflua 'Slender Silhouette' | Slender Silhouette Sweetgum | |
| Quercus palustris | Pin Oak | |
| Tilia cordata 'Greenspire' | Greenspire Littleleaf Linden | |
| Small Ornamental Trees | Cercis canadensis 'Merlot' | Merlot Eastern Redbud |
| Cornus kousa | Kousa Dogwood | |
| Crataegus x lavallei | Lavalle Hawthorn | |
| Magnolia x 'Ann' | Ann Magnolia | |
| Prunus x yedoensis 'Akebono' | Akebono Cherry | |
| Coniferous Trees | Picea sitchensis | Sitka Spruce |
| Pseudotsuga menziesii | Douglas Fir | |
| Thuja plicata | Western Red Cedar | |
| Large Shrubs | Amelanchier alnifolia | Saskatoon Berry |
| Cornus stolonifera | Red-osier Dogwood | |
| Hydrangea paniculata 'Limelight' | Limelight Hydrangea | |
| Physocarpus opulifolius 'Diabolo' | Diabolo Ninebark | |
| Sambucus nigra 'Black Lace' | Black Lace Elderberry | |
| Syringa x 'Bloomerang' | Bloomerang Lilac | |
| Medium Shrubs | Ceanothus x 'Victoria' | Victoria California Lilac |
| Polystichum munitum | Western Sword Fern | |
| Rosa 'Meidiland' | Meidiland Rose | |
| Spiraea japonica 'Little Princess' | Little Princess Spiraea | |
| Vaccinium ovatum | Evergreen Huckleberry | |
| Small Shrubs / Groundcovers | Arctostaphylos uva-ursi | Kinnikinnick |
| Gaultheria shallon | Salal | |
| Lavandula angustifolia | English Lavender | |
| Mahonia repens | Creeping Mahonia | |
| Pachysandra terminalis | Japanese Spurge | |
| Thymus serpyllum | Mother of Thyme | |
| Perennials | Coreopsis verticillata 'Moonbeam' | Moonbeam Tickseed |
| Echinacea purpurea 'Magnus' | Magnus Coneflower | |
| Hemerocallis 'Stella d'Oro' | Stella d'Oro Daylily | |
| Rudbeckia fulgida 'Goldsturm' | Goldsturm Black-eyed Susan | |
| Grasses | Calamagrostis x acutiflora 'Karl Foerster' | Karl Foerster Feather Reed Grass |
| Miscanthus sinensis 'Gracillimus' | Maiden Grass | |
| Panicum virgatum 'Shenandoah' | Shenandoah Switchgrass |
Professional Notice
The drawings, design ideas and features of construction depicted herein are the exclusive property of Forsite Landscape Architecture. All common-copy and property rights are expressly reserved. They are not to be reused, copied, reproduced, or used for any purposes nor are they to be assigned to a third party without expressed written consent. In the event of any unauthorized use of these plans by a third party, the third party shall not hold Forsite Landscape Architecture responsible.
