APPENDIX C – HARD SURFACE ABOVE TREE ROOTS DETAIL

December 5, 2023Pages 156–1572 sections

Technical diagrams and notes detailing the required construction methods for installing hard surfaces over critical root zones to protect tree health.

1 CALL TO ORDER
Requires use of geogrid reinforcement and clear crushed gravelExcavation must be supervised by a project arboristRequires medium weight geotextile fabric

APPENDIX C – HARD SURFACE ABOVE TREE ROOTS DETAIL

Construction Impact Assessment and Tree Management Plan for 339, 341, 345 Island Highway Prepared for Boardwalk REIT

Page 156–157

HARD SURFACE ABOVE TREE ROOTS DETAIL

[Diagram: Cross-section view showing the installation of a hard surface above tree roots with numbered components 1 through 8.]

HARD SURFACE ABOVE TREE ROOTS NOTES

  1. Maintain as large a setback between the fill encroachment and the root collar of the tree as possible.
  2. Review any canopy clearance pruning requirements to accommodate vehicle or pedestrian clearances (Pruning to be performed to ANSI A300 standards).
  3. Excavate the new footprint of the driveway or sidewalk under the supervision of the project arborist. Excavation will be limited to the removal of the existing sod layer. Excavation around root structures must be performed by hand, airspade, or hydroexcavation.
  4. Install a two-dimensional (such as Combigrid 30/30) or Three-dimensional geogrid reinforcement.
  5. Install a 150mm depth layer of clear crushed gravel (no fines) using 20mm and/or 75mm diameter material or approved equivalent. *Note - the depth may be less than 150mm in some situations (dependant on grading constraints).
  6. Install meduim weight geotextile fabric (such as Nilex 4535 or similar) over the clear crushed gravel layer to prevent fine particles of sand from infiltrating this layer.
  7. The bedding or base layer and new driveway or sidewalk surface can be installed directly on top of the felted filter fabric.
  8. Fill slopes - where possible install loose stacked boulders to reduce the footprint of the fill slopes that encroach within the critical root zone. Fill slope materials must be permeable to air and water. Do not pile fill material directly against the trunk of a tree.
