Detailed fire flow requirement calculations for Building B based on Fire Underwriters Survey (FUS) standards.
Building BTotal Fire Flow Requirement: 14000 L/minDate: 9-Oct-19
WATER SUPPLY FOR PUBLIC FIRE PROTECTION
Job Name: 9 Erskine Lane
Job #: 2253
Date: 9-Oct-19
Name: K. Krajnc
Building B
A. TYPE OF CONSTRUCTION
| Type of Construction | Value |
|---|---|
| Fire-Resistive Construction | 0.6 |
| Non-combustible Construction | 0.8 |
| Ordinary Construction | 1.0 |
| Wood Frame Construction | 1.5 |
| C = | 1.5 |
B. GROUND FLOOR AREA
1282 m² (1st)
C. HEIGHT OF BUILDING IN STOREYS
| Height | (Number of floors) | *Average Area Total: |
|---|---|---|
| 5 | 6410 m² |
D. FIRE FLOW FORMULA
F = 220 · C √ A
- C: 1.5
- A: 6410 m²
- F: 26421 L/min
- F (Nearest 1000): 26000 L/min
E. TOTAL DECREASE FOR OCCUPANCY
| Occupancy Type | Percentage |
|---|---|
| Non-Combustible | -25% |
| Limited Combustible | -15% |
| Combustible | No Change |
| Free Burning | 15% |
| Rapid Burning | 25% |
- O = -25 %
- T = -6500 L/min
- Tt = 19500 L/min
F. DECREASE FOR SPRINKLER PROTECTION
50% for complete automatic protection
30% for adequately designed systems
10% for water supply standard to both domestic and fire department hose lines required
10% for fully supervised system
T = 50 %
T = 9750 L/min
G. TOTAL INCREASE OF EXPOSURES
| Separation | Charge | Separation | Charge |
|---|---|---|---|
| 0 to 3m | 25% | 20.1 to 30m | 10% |
| 3.1 to 10m | 20% | 30.1 to 40m | 5% |
| 10.1 to 20m | 15% | >45m | 0% |
- N = 0%
- S = 0%
- E = 10%
- W = 10%
- Total charge: 20%
- T = 20%
- T = 3900 L/min
H. TOTAL FIRE FLOW REQUIREMENT
- E = 19500 L/min
- F = 9750 L/min
- G = 3900 L/min
| Total Calculation | Value | Unit |
|---|---|---|
| Total = | 13650 | L/min |
| Total = | 14000 | L/min |
| Total = | 233.3 | L/sec |
| Total = | 3698.4 | USGal/min |
| Total = | 3079.6 | IGal/min |
