Appendix: Location Plan

November 17, 2020Page 2481 section

An aerial site location plan showing the subject property boundaries and existing geotechnical features such as rock walls and slopes.

1 CALL TO ORDER
9 Erskine LaneJuly 2019Ryzuk GeotechnicalProposed 5-6 Story Building location indicated

LOCATION PLAN

Proposed 5-6 Story Building - 9 Erskine Lane, View Royal, B.C.

Aerial location plan for 9 Erskine Lane showing property boundaries, surrounding infrastructure such as Victoria General Hospital and Trans-Canada Hwy, and geological site classifications.
Aerial location plan for 9 Erskine Lane showing property boundaries, surrounding infrastructure such as Victoria General Hospital and Trans-Canada Hwy, and geological site classifications.

LEGEND

  • Bedrock at surface - Site Class 'A': [Green diagonal hatching]
  • Inferred Clay Deposit - Site Class 'C': [Blue diagonal hatching]

Map Callouts and Features

  • Victoria General Hospital
  • Rock Cuts (3-4 m high)
  • Rock Wall (8-10 m high)
  • Cut Slope (8-10 m high)
  • HOSPITAL WAY
  • Watkiss Way
  • Property Line
  • Victoria Water Main Right of Way
  • Erskine Lane
  • TRANS-CANADA HWY

Notes

Base imagery obtained from CRD Webmap 2017 aerial photography.

Plan Information Details
Client Westurban Developments Ltd.
Project LOCATION PLAN - Proposed 5-6 Story Building
Site Address 9 Erskine Lane, View Royal, B.C.
Drawn SJB
Date July, 2019
Scale 1:2950
Drawing No. 8298-3-1
Engineering Firm RYZUK GEOTECHNICAL Engineering & Materials Testing
Page 248
