Architectural Site Plan (Sheet A201)

June 16, 2020Page 511 section

Detailed architectural site plan showing building footprints for Buildings 1, 2, and 3, including setbacks and fire access lanes.

1 CALL TO ORDER
30,000mm width for Building 27500mm setbacks from property linesWoonerf style shared space identified

Eagle Nest Residences - 3 Helmcken Road, Victoria, BC

Architectural Site Plan

Rendered landscape and architectural site plan illustrating the layout of three proposed residential buildings, a central community green space, woonerf, feature rain garden, and retained landscape areas.
Rendered landscape and architectural site plan illustrating the layout of three proposed residential buildings, a central community green space, woonerf, feature rain garden, and retained landscape areas.

Project Name: Eagle Nest Residences Address: 3 Helmcken Road, Victoria, BC Drawing Title: Architectural Site Plan Drawing Number: A201 Project Number: 1827 Date: 27 FEB 2020 Scale: 1:250 Drawn By: NLC Checked By: RAW Status: ISSUED FOR REZONING

Revision Schedule

Rev Date Description
1 17 SEP 2018 ISSUED FOR REZONING
2 22 JAN 2020 ISSUED FOR REZONING
3 27 FEB 2020 ISSUED FOR REZONING

Proposed Building Summary

  • Building 1: 6 storeys. Includes sections at 5 storeys (Roof 44.0) and 4 storeys (Roof 40.9).
    • Note: Red annotation on plan states: "See proposed Bylaw for correction" over the Building 1 footprint.
  • Building 2: 4 storeys (+ 1/2 storey at P1). Roof heights noted at 41.9 and 40.9.
  • Building 3: 5 storeys. Includes a 4 storey section with a roof height of 40.9.

Site Features and Landscaping

  • Community Green: Centralized green space.
  • Woonerf: Shared street space for pedestrians and vehicles.
  • Feature Rain Garden: Located at the corner of Helmcken Road and Burnside Road.
  • Retained Natural Features: Areas designated for "Retained Trees and Landscape" and a "Retained Rock Outcrop" near Helmcken Road.
  • Access and Infrastructure:
    • Two parkade entry points from the north and northeast.
    • Fire truck access lane and turnaround (R 9000).
    • Bus stop located along Helmcken Road.
  • Setbacks and Dimensions:
    • Property line setbacks: 4000mm, 7500mm, and 8000mm.
    • Building setbacks from property lines: 10500mm, 11200mm, 13770mm, 16220mm, and 19985mm.
    • Interior site dimensions include widths of 8200mm, 8275mm, 30000mm, and 4100mm.
Page 51
