Cross-sectional drawing showing the building heights and underground parkade levels.
Building 1 height: 19.2 mBuilding 2 height: 14.8 mParkade levels P1 and P2
Eagle Nest Residences
3 Helmcken Road, Victoria, BC
Section
The architectural section drawing illustrates two residential buildings, Building 1 and Building 2, separated by a landscaped podium area. Both buildings sit atop a two-level underground parkade.
LEGEND
- 1 Bed
- 2 Bed
- Common Areas
- Parkade
Building 1 Elevation Data
- Building Height: 19.2 m
- Average Grade: 28.9
- Roof: 48.1
- L6: 44.0
- L5: 40.9
- L4: 37.8
- L3: 34.7
- L2: 31.6
- L1 Lobby: 28.5
Building 2 Elevation Data
- Building Height: 14.8 m
- Average Grade: 27.1
- Roof: 41.9
- L4: 37.8
- L3: 34.7
- L2: 31.6
- L1 Lobby: 28.5
Parkade Levels
- P1: 25.0
- P2: 21.5
Revision Schedule
| Rev | Date | Description |
|---|---|---|
| 17 SEP 2018 | ISSUED FOR REZONING | |
| 1 | 22 JAN 2020 | ISSUED FOR REZONING |
| 2 | 27 FEB 2020 | ISSUED FOR REZONING |
Project Information
| Field | Details |
|---|---|
| Plot Date | 27 FEB 2020 |
| Project Number | 1827 |
| Drawn By | NLC |
| Checked By | RAW |
| Scale | 1:150 |
| Drawing File | 1827 A501 Site Section.vwx |
| Drawing No. | A501 |
| Revision No. | 2 |
NOTE: All dimensions are shown in millimeters.
Page 59
