Public Hearing/Documents/Perspectives

Appendix

Perspectives

June 16, 2020Page 611 section

3D perspective renderings of the proposed Eagle Nest Residences from several street vantage points.

1 CALL TO ORDER

Views from Burnside and HelmckendHKarchitects

Eagle Nest Residences

3 Helmcken Road, Victoria, BC

Perspectives

Perspective view at Burnside and Helmcken

**AT BURNSIDE AND HELMCKEN**

Bird's eye perspective looking North East

**BIRD'S EYE - LOOKING NORTH EAST**

Perspective view looking North from Burnside

**LOOKING NORTH FROM BURNSIDE**

Bird's eye perspective looking North West

**BIRD'S EYE - LOOKING NORTH WEST**

Project Information

Field	Value
Project Number	1827
Date	27 FEB 2020
Scale	N.T.S.
Drawn By	EDS
Checked By	RAW
Drawing Title	Perspectives
Drawing No.	A602
Revision No.	2
Status	ISSUED FOR REZONING
Drawing File	1827 A100 Site Plan.vwx

Revision History

Rev	Date	Description
3	27 FEB 2020	ISSUED FOR REZONING
2	22 JAN 2020	ISSUED FOR REZONING
1	17 SEP 2018	ISSUED FOR REZONING

NOTE: All dimensions are shown in millimeters.

Page 61
