Public Hearing/Documents/Perspective Rendering
Appendix

Perspective Rendering

June 16, 2020Page 621 section

Artistic renderings and conceptual sections showing the site's public realm and internal courtyard.

1 CALL TO ORDER
BIRD'S EYE - LOOKING WESTAT BURNSIDE AND HELMCKEN

Eagle Nest Residences

3 Helmcken Road, Victoria, BC

BIRD'S EYE - LOOKING WEST

Aerial bird's eye view rendering of the development site and surrounding neighborhood, looking west
Aerial bird's eye view rendering of the development site and surrounding neighborhood, looking west

Site Sections

Architectural hand-drawn cross-sections titled "SECTION @ HIDDEN OAKS" and "SECTION @ HELMCKEN" showing building profiles and landscape
Architectural hand-drawn cross-sections titled "SECTION @ HIDDEN OAKS" and "SECTION @ HELMCKEN" showing building profiles and landscape

Perspective Rendering

AT BURNSIDE AND HELMCKEN

Artistic perspective sketch of the residential buildings and a central landscaped courtyard area with people
Artistic perspective sketch of the residential buildings and a central landscaped courtyard area with people

ISSUED FOR REZONING

Rev Date Description
1 17 SEP 2018 ISSUED FOR REZONING
2 22 JAN 2020 ISSUED FOR REZONING
2 27 FEB 2020 ISSUED FOR REZONING

Drawing Information

  • Project Name: Eagle Nest Residences
  • Address: 3 Helmcken Road, Victoria, BC
  • Drawing Title: Perspective Rendering
  • Project Number: 1827
  • Drawing No.: A603
  • Revision No.: 2
  • Date: 27 FEB 2020
  • Scale: N.T.S.
  • Drawn by: EDS
  • Checked by: RAW
  • Drawing File: 1827 A100 Site Plan.vwx

Architectural Firm dHKarchitects

  • Victoria Office: 977 Fort Street, Victoria BC V8V 3K3 | T 250-658-3367
  • Nanaimo Office: 102-5190 Dublin Way, Nanaimo BC V9T 0H2 | T 250-585-5810

NOTE: All dimensions are shown in millimeters.

COPYRIGHT RESERVED. THESE PLANS AND DESIGNS ARE AND AT ALL TIMES REMAIN THE PROPERTY OF DHKARCHITECTS TO BE USED FOR THE PROJECT SHOWN AND MAY NOT BE REPRODUCED WITHOUT WRITTEN CONSENT.

Page 62
