Eagles Nest Residences Site Plan

June 16, 2020Page 1341 section

An architectural site plan showing the proposed layout of the Eagles Nest Residences, including buildings ranging from 3 to 6 storeys.

1 CALL TO ORDER
dHKarchitectsBuildings: 3, 4, 5, and 6 storeysIncludes Community Green and Woonerf

Eagles Nest Residences

Site Plan

Revision Schedule

Rev Date Description
1 17 SEP 2018 ISSUED FOR REZONING
1 28 JUN 2019 RE-ISSUED FOR REZONING
1 22 JAN 2020 RE-ISSUED FOR REZONING

Project Details

  • Project Name: Eagles Nest Residences
  • Location: Helmcken Rd, View Royal BC
  • Drawing Title: Site Plan
  • Drawing Number: A101
  • Project Number: 1827
  • Date: 22 JAN 2020
  • Scale: 1:250
  • Drawn by: EDS
  • Checked by: RAW

Office Locations

  • Victoria Office: 977 Fort Street, Victoria BC V8V 3K3 | T 1 • 250 • 658 • 3367
  • Nanaimo Office: 102 - 5190 Dublin Way, Nanaimo BC V9T 0H2 | T 1 • 250 • 585 • 5810
Detailed site plan map illustrating the development layout for Eagles Nest Residences, bounded by Helmcken Road to the south, Burnside Road to the east, and property lines to the north and west. The development consists of multiple connected building masses with labeled heights: 6 STOREYS, 5 STOREYS, 4 STOREYS, 4 STOREYS (WITH PARTIAL 5TH FLOOR), and 3 STOREYS. Key site features include a central "COMMUNITY GREEN," a "WOONERF," "PRESERVED TREES AND LANDSCAPE" areas, a "PRESERVED ROCK OUTCROP," and a "FEATURE RAIN GARDEN." Dimension callouts in millimeters include 19789, 14352, 11438, 11185, 19324, 10572, 8226, and 8359. Spot elevations such as 25.50, 24.26, and 21.10 are also indicated.
Detailed site plan map illustrating the development layout for Eagles Nest Residences, bounded by Helmcken Road to the south, Burnside Road to the east, and property lines to the north and west. The development consists of multiple connected building masses with labeled heights: 6 STOREYS, 5 STOREYS, 4 STOREYS, 4 STOREYS (WITH PARTIAL 5TH FLOOR), and 3 STOREYS. Key site features include a central "COMMUNITY GREEN," a "WOONERF," "PRESERVED TREES AND LANDSCAPE" areas, a "PRESERVED ROCK OUTCROP," and a "FEATURE RAIN GARDEN." Dimension callouts in millimeters include 19789, 14352, 11438, 11185, 19324, 10572, 8226, and 8359. Spot elevations such as 25.50, 24.26, and 21.10 are also indicated.

General Notes

  • All dimensions are shown in millimeters.
  • COPYRIGHT RESERVED. THESE PLANS AND DESIGNS ARE AND AT ALL TIMES REMAIN THE PROPERTY OF DHKARCHITECTS TO BE USED FOR THE PROJECT SHOWN AND MAY NOT BE REPRODUCED WITHOUT WRITTEN CONSENT.
