Public Hearing/Documents/APPENDIX C: DEDICATED RIGHT TURN LANE CONCEPT PLAN
Appendix

APPENDIX C: DEDICATED RIGHT TURN LANE CONCEPT PLAN

June 16, 2020Pages 258–2591 section

Engineering concept plan for a second westbound through lane and right turn lane at the Helmcken Road and Watkiss Way intersection.

1 CALL TO ORDER
2ND WB THRU LANE & RIGHT LANEDecember 21, 2018

APPENDIX C: DEDICATED RIGHT TURN LANE CONCEPT PLAN

Eagle Nest Helmcken Road Report

2ND WB THRU LANE & RIGHT LANE HELMCKEN RD / WATKISS WAY EAGLE NEST TIA

Aerial map overview of the intersection at Helmcken Road, Watkiss Way, and Chancellor Ave with proposed lane markings
Aerial map overview of the intersection at Helmcken Road, Watkiss Way, and Chancellor Ave with proposed lane markings
Aerial view of residential properties and road segments within the concept plan area
Aerial view of residential properties and road segments within the concept plan area
Aerial view focusing on parking lots and roadway alignment
Aerial view focusing on parking lots and roadway alignment
Detailed aerial view of individual land parcels
Detailed aerial view of individual land parcels

CONCEPT DESIGN ONLY - NOT FOR CONSTRUCTION

Project Information

  • Designed: MJO
  • Drawn: MJO
  • Project No: 2497.B01
  • Drawing No: S-2
  • Date: DEC 21-2018
  • Revision: 0
  • Scale: 1:1,000

Note: These Design Documents are prepared solely for the use by the party with whom the Design Professional has entered into a contract, and there are no representations of any kind made by the Design Professional to any party with whom the Design Professional has not entered into contract.

Contact Information #501, 740 - Hillside Ave Victoria, BC V8B TZ4 T. 250.388.9877 F. 250.388.9879 www.wattconsultinggroup.com

Page 258–259
