Appendix
Building Height Above Ground Level Diagram
June 16, 2020Page 3241 section
A 3D visualization of the proposed development in context with surrounding building heights measured in meters and feet.
Max height shown: 19.9m (65'3")Neighboring building heights included for comparison
Building Height Site Model
The following building heights are indicated on the site model:
- 21m - 68'10"
- 25m - 82'
- 6m - 19'8"
- 6m - 19'8"
- 18m - 59'
- 14m - 45'11"
- 5m - 16'5"
- 24.37m - 79'11"
- 26.43m - 86'8"
- 9m - 29'6"
- 11m - 36'1"
- 8m - 26'3"
- 13.7m - 44'11"
- 16.8m - 55'1"
- 19.9m - 65'3"
- 13.7m - 44'11"
- 10.6m - 34'9"
- 16.8m - 55'1"
- 13.7m - 44'11"
- 13.7m - 44'11"
- 10.6m - 34'9"
Page 324
