Sub-Zone Diagram - dHKarchitects

June 16, 2020Page 3361 section

A detailed technical site plan showing three sub-zones, building footprints, and setbacks from property lines.

2 APPROVAL OF AGENDA
Feb 27, 2020Scale 1:250Sub-zone 1: 5,788 lot area; Sub-zone 2: 4,023 lot area; Sub-zone 3: 3,950 lot area

Sub-Zone Diagram

Landscape and site plan showing the proposed development with three sub-zones, building footprints, a community green, and a woonerf.
Landscape and site plan showing the proposed development with three sub-zones, building footprints, a community green, and a woonerf.

Project Information

  • Project Name: Eagle Nest Residences
  • Address: 3 Helmcken Road, Victoria, BC
  • Project Number: 1827
  • Date: 27 FEB 2020
  • Drawing Number: A101
  • Revision: 2
  • Scale: 1:250
  • Drawn by: NLC
  • Checked by: RAW
  • Drawing File: 1827 A200 Floor Plan.vwx

Sub-Zone Details

Sub-Zone Lot Area FSR Building Storeys
SUB-ZONE 1 5,788 1.49 BUILDING 1 6 storeys
SUB-ZONE 2 4,023 1.49 BUILDING 2 4 storeys (+ 1/2 storey at P1)
SUB-ZONE 3 3,950 1.48 BUILDING 3 5 storeys

Site Features and Setbacks

  • Community Green
  • Woonerf
  • Feature Rain Garden
  • Retained Rock Outcrop
  • Retained Trees and Landscape
  • Property Line
  • Setback Dimensions (mm):
    • 8000
    • 7500
    • 6723
    • 2812
    • 17719
    • 17872
    • 6168
    • 7453
    • 3300
    • 4829
    • 4000
  • Infrastructure:
    • Burnside Road (R 9000, 6000)
    • Helmcken Road
    • Bus Stop

Revisions

Rev Date Description
1 17 SEP 2018 ISSUED FOR REZONING
2 22 JAN 2020 ISSUED FOR REZONING
2 27 FEB 2020 ISSUED FOR REZONING

Contact Information

  • VICTORIA OFFICE: 977 Fort Street, Victoria BC V8V 3K3 | T 1 • 250 • 658 • 3367
  • NANAIMO OFFICE: 102 - 5190 Dublin Way, Nanaimo BC V9T 0H2 | T 1 • 250 • 585 • 5810

Notes

  • All dimensions are shown in millimeters.
Page 336
