Attachment 3: Block A Plans Level 01 - Eric Barker Architect inc.

March 4, 2014Page 171 section

Floor plans for Level 01 of Block A showing unit configurations.

1 CALL TO ORDER
May 1, 2013Eric Barker Architect inc.

FOUR MILE ESTATES

Block A Plans Level 01

Architectural floor plan for Block A Level 01, depicting four townhouse units (Block A Unit 1 through Unit 4). The plan shows the ground floor layout including garages, entryways, patio pavers, and concrete sidewalks, along with structural and site dimensions.
Architectural floor plan for Block A Level 01, depicting four townhouse units (Block A Unit 1 through Unit 4). The plan shows the ground floor layout including garages, entryways, patio pavers, and concrete sidewalks, along with structural and site dimensions.
Project Data Details
Project Number 211078
Sheet Issue Date 05/21/13
Drawn by JJ & MP
Checked by Checker
Scale As indicated
Drawing No. A2.1.2

Revision Schedule

No. Date Description
1 DP AMENDMENT

Architect Information ERIC BARKER ARCHITECT inc. 727 PANDORA AVENUE, VICTORIA, B.C. (250) 383-4333 Fax: (250) 383-4333

Key Plan

Drawing Notes and Dimensions

  • Scale Designation: BLOCK A Level 1 (3/16" = 1'-0")
  • Unit Designations:
    • Block A Unit 1
    • Block A Unit 2
    • Block A Unit 3
    • Block A Unit 4
  • Structural Reference Lines:
    • 1-a, 1-b, 1-c, 1-d, 1-e
    • TO FACE OF SHEATHING
    • CENTRELINE OF PARTY WALL
  • Setbacks and Site Features:
    • 3.50 m Setback
    • 5.03 m SETBACK TO FACE OF SHEATHING
    • PROPERTY LINE: 13.6 m (44'-6")
    • Retaining Wall
    • Conc. Sidewalk
    • Patio Pavers
  • Primary Unit Dimensions:
    • Unit Width: 24'-8"
    • Interior Unit Widths: 13'-1 1/2", 11'-9 1/2" (typical)
Page 17
Extracted from: 2014 03 04 Council Agenda
