Council Meeting/Documents/Attachment 5: Block B Plans Level 01 - Eric Barker Architect inc.
Appendix

Attachment 5: Block B Plans Level 01 - Eric Barker Architect inc.

March 4, 2014Page 191 section

Floor plans for Level 01 of Block B showing unit configurations.

1 CALL TO ORDER
February 4, 2014Eric Barker Architect inc.

FOUR MILE ESTATES

Block B Plans Level 01

DP AMENDMENT

Project Information Details
Project Number 211070
Sheet Issue Date 02/04/2014
Drawn By JB & NP & RC
Checked By Checker
Scale As indicated
Sheet Number A2.2.2
Architectural drawing sheet A2.2.2 showing the Level 01 floor plans for Block B, Units 5 through 8. The plan includes a key plan, building dimensions, setback requirements, and internal unit layouts featuring garages and patios.
Architectural drawing sheet A2.2.2 showing the Level 01 floor plans for Block B, Units 5 through 8. The plan includes a key plan, building dimensions, setback requirements, and internal unit layouts featuring garages and patios.

Plan Details and Dimensions

  • Unit Type: BLOCK B TYPE B UNIT
  • Total Building Width: 29.77 m (97' - 8")
  • Units Included:
    • Block B Unit 5
    • Block B Unit 6
    • Block B Unit 7
    • Block B Unit 8
  • Setbacks:
    • 3.05 m Setback to face of sheathing
    • 5.05 m Setback to face of sheathing
    • 5M Setback (Side)
    • 5M Front Yard
  • Site Features:
    • Centreline of party walls
    • Concrete sidewalks
    • Patio pavers
    • Garage layouts
  • General Note: ALL DIMENSIONS FACE OF CONCRETE / SHEATHING TO STUD.

Revision History

No. Date Description
DP AMENDMENT
Page 19
Extracted from: 2014 03 04 Council Agenda
