Council Meeting/Documents/BUILDING ENVELOPES ON PROPOSED STRATA LOTS 1 TO 4 (Attachment 4)
Appendix

BUILDING ENVELOPES ON PROPOSED STRATA LOTS 1 TO 4 (Attachment 4)

May 6, 2014Page 701 section

Survey plan illustrating building envelopes for the proposed four-lot subdivision.

1 CALL TO ORDER
February 18, 2014

BUILDING ENVELOPES ON PROPOSED STRATA LOTS 1 TO 4, SECTION 3, ESQUIMALT DISTRICT, STRATA PLAN EPS

ATTACHMENT 4

Survey map showing building envelopes for Proposed Strata Lot 1, Proposed Strata Lot 2, Proposed Strata Lot 3, and Proposed Strata Lot 4, with Proposed Common Property and bordering Plowright Road.
Survey map showing building envelopes for Proposed Strata Lot 1, Proposed Strata Lot 2, Proposed Strata Lot 3, and Proposed Strata Lot 4, with Proposed Common Property and bordering Plowright Road.

Plan Details

  • Scale: 1:200
  • Date: February 18, 2014
  • File: 56-ANX-M930-2

Proposed Site Features

  • PLOWRIGHT ROAD
  • Proposed Common Property
  • Proposed Strata Lot 1
  • Proposed Strata Lot 2
  • Proposed Strata Lot 3
  • Proposed Strata Lot 4

Adjacent Properties

  • 2 PLAN 7873
  • 1 PLAN 35414
  • A PLAN 18092
  • PT. 21
  • PLAN 3738 (Parcels 22, 23, 24, 25)
  • B PLAN VIP71462
  • A PLAN VIP71462
  • PT. F PLAN 3823
  • 1 PLAN 40670
  • 2 (South of Plan 40670)

Notes

  • Note: All distances are in meters.
  • Dimensions and areas shown are based on and for office records and may vary upon completion of a comprehensive land survey.
  • This plan must be approved by legal authority prior to building.

Surveyor Information

Island Land Surveying Ltd. 758B Clover Avenue, Victoria, B.C. V8X 2S7 Tel: (250) 475-1212 Fax: (250) 475-1210 www.islandlandsurveying.ca

Page 70
Extracted from: 2014 05 06 Council Agenda
