EXISTING STRUCTURES ON PROPOSED STRATA LOTS 1 TO 4 (Attachment 5)

EXISTING STRUCTURES ON PROPOSED STRATA LOTS 1 TO 4, SECTION 3, ESQUIMALT DISTRICT, STRATA PLAN EPS ____

Scale 1:200

Proposed Strata Lots 1 to 4 may be subject to changes.

Right of Way 1127155 & 1127160
Statutory Right of Way EB62074

Site plan map showing four proposed strata lots and common property access from Plowright Road. The plan identifies existing structures with civic addresses #910, #1262, #914, and #256, as well as an auxiliary building. The map includes lot dimensions, surrounding plan numbers, and lot designations.

R-1 Zone	Minimum Requirements	Proposed Strata Lot 1	Proposed Strata Lot 2	Proposed Strata Lot 3	Proposed Strata Lot 4
Front Yard	7.5m	-	21.0m+	-	15.0m+
Rear Yard	7.5m	-	7.5m	-	8.5m
Side Yard	2.4m, provided sum of the two side yards is not less than 6.0m	-	2.2m and 4.3m, totaling 6.5m	-	1.9m and 4.1m, totaling 6.0m
Lot Area	1000 Sq. m	1002 Sq. m	1002 Sq. m	1002 Sq. m	1002 Sq. m
Lot Width	18.0m	24.1m	18.3m	20.7m	28.3m
Gross Floor Area	40% of lot area, not to exceed 272 Sq. m	-	19% or 201 Sq. m.	-	19% or 254 Sq. m.

Note: Location of existing structures and floor areas have been provided by client. For planning purposes only. Dimensions and areas shown are based on land title office records and may vary upon completion of a comprehensive legal survey. This plan must be approved by planning authorities prior to reliance.

File: 35-L-41A-48154-4 Date: July 16, 2013

Island Land Surveying Ltd. 1-435 Simcoe Avenue Victoria BC V8V 4T2 Tel (250) 388-4100 Fax (250) 388-4101 www.island-surveying.ca
