Site Landscaping Plan L1 - Cung Residence

October 21, 2014Page 811 section

Detailed landscape plan for 237 Anya Lane showing the main residence and surrounding environment.

1 CALL TO ORDER
September 23, 2014Outline Home Design

ATTACHMENT 8

outline HOME DESIGN

www.outlinehomedesign.com p: 250 818 3951 e: info@outlinehomedesign.com

PROJECT ADDRESS 237 Anya Lane View Royal BC

Lot 24, Section 98 Esquimalt District, Plan VIS568

PID 027-334-333 ZONE R1 LOT AREA 4097.7 m2

Site Landscaping plan for Cung Residence at 237 Anya Lane showing the main residence, garage, patio, deck, field level, and proximity to Millstream and a park.
Site Landscaping plan for Cung Residence at 237 Anya Lane showing the main residence, garage, patio, deck, field level, and proximity to Millstream and a park.

Plan Labels and Annotations

  • P75
  • FIELD 15000 FT2
  • FIELD LEVEL
  • COMPACTED GRAVEL
  • DECK 24'-0" x 16'-0"
  • SHORELINE DEVELOPMENT PERMIT AREA
  • PARK
  • millstream
  • patio
  • main residence
    • MAIN FLOOR ELEVATION 14.75m
    • BASEMENT ELEVATION 11.42m (11.72m)
  • garage
  • access to field
  • grass strip
  • permeable paving strip 'grass crete' or equiv.
TITLE Site Landscaping
PROJECT Cung Residence, 237 Anya Lane
FILE Ad26.14
SCALE 1/8" = 1'-0"
PROJECT NO 1440
DATE Sept 23, 2014
DRAWN BY Tim Rodier
SHEET NO L1
