Attachment 6 - Site Plan of the Remainder of Lot 22

Site Plan of the Remainder of Lot 22, Section 98, Esquimalt District, Plan 748

Scale 1 : 250 All distances are shown in metres. Elevations indicated are in metres, to geodetic datum.

Legend

• wm - denotes water meter
• wv - denotes water valve
• icv - denotes irrigation control valve
• gm - denotes gas meter
• mh - denotes manhole
• mls - denotes metal light standard
• up - denotes utility pole
• cb - denotes catch basin drain
• co - denotes clean out
• s/c - denotes service cover
• inv - denotes invert

* * Restrictive Covenants on all except Part in Lease Plan VIP60554 * *

Site Plan Details

The plan depicts the following areas and features:

• Properties: Rem 23 Plan 748, Rem 22 Lease Plan VIP60554, and Rem 1 Plan 5775.
• Roadways: Old Island Highway.
• Buildings and Structures:
  • Commercial/retail building
  • Loading bay
  • New storage area
  • Old building location
  • Retaining walls
• Ground Cover: Asphalt parking lots, asphalt surfaces, and grass areas.
• Survey Measurements and Annotations:
  • North boundary of Lot 22: 174.90 +/-
  • South boundaries: 31.6 +/-, 18.9 +/-, and 68.27
  • East boundary along Old Island Highway: 55.08
  • Building heights/elevations: peak = 22.25, parapet = 20.10, parapet = 19.99, parapet = 21.02, parapet = 20.40, eave = 20.73.
  • Address reference: No 1658

Revision and Surveyor Information

rev April 4, 2014 rev February 3, 2012 May 3, 2003

File: 8758 S-14 (104) POWELL & Associates BC LAND SURVEYORS 250-2950 Douglas Street Victoria, BC V8L 4N4 phone (250) 382-8855
