Attachment 7 - Site Plan (Drawing A2.1)

July 2, 2014Page 361 section

Proposed site layout showing the footprint of the new building addition and parking configurations.

1 CALL TO ORDER
May 5, 2014

SIX MILE FURNITURE PROPOSED ADDITION

DEVELOPMENT PERMIT APPLICATION

1644 & 1652 OLD ISLAND HIGHWAY, VICTORIA BC

Site plan for the Six Mile Furniture proposed addition showing the layout of existing buildings (Six Mile Furniture, KMS Tools, 4x4 Repair) and proposed new spaces (Shell Space and Furniture Addition). The plan includes parking configurations, site grades, property boundaries, and setbacks relative to Old Island Highway and a natural boundary.
Site plan for the Six Mile Furniture proposed addition showing the layout of existing buildings (Six Mile Furniture, KMS Tools, 4x4 Repair) and proposed new spaces (Shell Space and Furniture Addition). The plan includes parking configurations, site grades, property boundaries, and setbacks relative to Old Island Highway and a natural boundary.

Drawing Title: SITE PLAN
Scale: 1:250
Date: 05 MAY 2014
Drawing Number: A2.1

Site Plan Data

Building Areas and Elevations:

  • Proposed Shell Space: 134 m² (1,442 F²)
    • 100.00 Main Floor Elevation
    • 14.900m GEO
  • Existing Six Mile Furniture:
    • 100.00 Existing Floor Elevation
    • 14.900m GEO
  • Proposed Six Mile Furniture Addition: 1859 m² (20,010 F²)
    • 100.00 Main Floor Elevation
    • 14.900m GEO
  • Existing KMS Tools:
    • 99.900 Existing Floor Elevation
    • 14.800m GEO

Site Legend:

Symbol Description
17.750 EXISTING GRADE (GEO)
20.000 PROPOSED FINISHED GRADE (GEO)

Other Noted Features:

  • Existing 4x4 Repair
  • Existing Building
  • Drive Aisle
  • Loading Dock
  • Sidewalk
  • Entrance
  • Setback lines
  • Small car parking stalls
  • Present Natural Boundary
  • Old Island Highway
