Attachment 8 - Main Floor Plan (Drawing A2.2)

July 2, 2014Page 371 section

Internal layout plan for the proposed showroom and warehouse addition.

1 CALL TO ORDER
May 5, 2014

SIX MILE FURNITURE PROPOSED ADDITION

DEVELOPMENT PERMIT APPLICATION

1644 & 1652 OLD ISLAND HIGHWAY, VICTORIA BC

Main floor plan architectural drawing showing the existing and proposed spaces for Six Mile Furniture and KMS Tools, including a proposed shell space, warehouse, sales area, and a large showroom with ancillary service rooms.
Main floor plan architectural drawing showing the existing and proposed spaces for Six Mile Furniture and KMS Tools, including a proposed shell space, warehouse, sales area, and a large showroom with ancillary service rooms.

MAIN FLOOR PLAN

Date: 05 MAY 2014

Floor Plan Labels and Areas:

  • Proposed Shell Space
    • 4 hr. fire separation
    • Entrance
  • Existing Six Mile Furniture Warehouse
    • Relocated existing door
  • Existing Six Mile Furniture Sales
  • Proposed Show Room
    • Office
    • Sales
    • Closet
    • Lunch Room
    • Women's Washroom
    • Men's Washroom
    • 4 hr. fire separation
    • Fire rated shutter
    • 2 hr. fire separation
    • Entrance
    • Storage Room
    • Ladder to Roof
    • Mech./Elec. Room
    • Electrical Room
  • Existing KMS Tools
  • Exterior Features: Sidewalk

The plan includes a coordinate grid (A4 through G horizontally and 1 through 6 vertically) and various dimensions.

Page 37
