Attachment 12 - Building Sections (Drawing A4.1)

July 2, 2014Page 411 section

Cross-sectional drawings of the proposed construction.

1 CALL TO ORDER

SIX MILE FURNITURE PROPOSED ADDITION - DEVELOPMENT PERMIT APPLICATION

1644 & 1652 OLD ISLAND HIGHWAY, VICTORIA BC

Architectural drawing sheet A4.1 showing four building sections (A, B, C, and D) for the proposed addition and existing buildings.
Architectural drawing sheet A4.1 showing four building sections (A, B, C, and D) for the proposed addition and existing buildings.

BUILDING SECTIONS

  • Drawing Number: A4.1
  • Date: 05 MAY 2014
  • Scale: 1:100

BUILDING SECTION A - EAST/WEST

  • Scale: 1:100
  • Key Features:
    • Existing KMS Tools building
    • Proposed Show Room
    • 4 HR. Fire Separation
    • Glazing
  • Grid Line Spacing (mm):
    • 6 to 5: 11180
    • 5 to 4: 11180 (Total 6 to 4: 22360)
    • 4 to 3: 5350
    • 3 to 2: 4490
    • 2 to 1: 1940
  • Elevations:
    • T.O. ROOF Q-DECK (+/-): 104.485
    • DRIVE AISLE
    • T.O. MAIN FLOOR SLAB: 100.00
    • AVERAGE EXISTING GRADE: 99.510 (21.15' CD)

BUILDING SECTION B - NORTH/SOUTH

  • Scale: 1:100
  • Key Features:
    • Existing Six Mile Furniture Sales building
    • Proposed Show Room
    • 4 HR. Fire Separation
  • Grid Line Spacing (mm):
    • A to B: 9195
    • B to C: 9295
    • C to D: 9295
    • D to E: 9295
    • E to F: 9295
    • F to G: 9195
  • Elevations:
    • T.O. ROOF Q-DECK (+/-): 104.485
    • DRIVE AISLE
    • T.O. MAIN FLOOR SLAB: 100.00
    • AVERAGE EXISTING GRADE: 99.510 (24.15' CD)

BUILDING SECTION C - EAST/WEST

  • Scale: 1:100
  • Key Features:
    • Existing Six Mile Furniture Warehouse
    • Proposed Addition
    • 4 HR. Fire Separation
  • Grid Line Spacing (mm):
    • 3 to 2: 4490
  • Elevations:
    • T.O. ROOF Q-DECK (+/-): 102.485
    • DRIVE AISLE
    • T.O. MAIN FLOOR SLAB: 100.00
    • AVERAGE EXISTING GRADE: 99.510

BUILDING SECTION D @ ENTRANCE

  • Scale: 1:100
  • Key Features:
    • Proposed Addition
    • Entrance
    • Walkway
    • Canopy
  • Dimensions:
    • Entrance width: 3000 mm
  • Elevations:
    • T.O. ROOF Q-DECK (+/-): 106.715
    • T.O. ROOF Q-DECK (+/-): 104.485
    • T.O. MAIN FLOOR SLAB: 100.00
    • AVERAGE EXISTING GRADE: 99.510
Page 41
