Attachment 4 - Photos Existing Carport and Proposed Single Car Garage Elevation

September 20, 2022Page 241 section

Visual documentation including site photos and architectural sketches for the proposed garage.

1 CALL TO ORDER
Attachment 4August 15, 2022

Proposed Single Car Garage - Site Plan and Elevation

Site plan showing the existing residence and the layout for the proposed single-car garage with property dimensions, line of easement, and fence line
Site plan showing the existing residence and the layout for the proposed single-car garage with property dimensions, line of easement, and fence line

Project Notes

  • Proposed single car garage scale 1:50
  • Changed direction of slope to allow for future solar panels
  • 10.10 Natural Grade
  • 9.60 Average Grade Calculation
  • 0.06 M Clearance Required
  • 1.8.0 M Clearance

Building Assemblies and R-Value Calculations

Floor Assembly

FLOOR ASSEMBLY R
COMPACTED SUB BASE 0.00
CONCRETE 0.00
TOTAL N/A

Exterior Wall Assembly

EXTERIOR WALL ASSEMBLY R
½" HARDIE PLANK LAP SIDING 1.08
EXTERIOR AIR FILM 0.17
MOISTURE BARRIER 0.00
½" PLYWOOD SHEATHING 0.94
5.5" INSULATION (FIBERGLASS) 12.95
2X6 WALL STUDS@16" O.C 0.00
A/V BARRIER 0.00
½" GYPSUM BOARD 0.45
TOTAL 15.59 (R) 2.74 (RSI)

Roof Assembly

ROOF ASSEMBLY R
2-PLY BIT. ROOFING 0.00
MANUFACTURER APPROVED 0.00
UNDERLAY 0.00
½" PLYWOOD SHEATHING 0.94
ROOF FRAMING AT 24" O.C 0.00
10" INSULATION (FIBERGLASS) 30.00
A/V BARRIER 0.00
5/8" GYPSUM BOARD 0.57
TOTAL 31.51 (R) 5.55 (RSI)

Environmental and Seismic Design Data

Design Temperature Degree Days Below 18°C
January 2.5% °C July 2.5% Dry °C / Wet °C
-6 17 / 14 2700
15 Min. Rain, mm One Day Rain, mm Ann. Rain, mm Moist. Index Ann. Tot. Pptn. mm Driving Rain Wind Pressure, Pa, 1/5
1.6 136 600 0.90 825 220
Snow Load kPa 1/50 Hourly Wind Pressures, kPa
Ss Sr 1/10 1/50
1.3 0.3 0.44 0.57
Seismic Data
Sa(0.2) Sa(0.5) Sa(1.0) Sa(2.0) Sa(5.0) Sa(10.0) PGA PGV
1.3 1.16 0.678 0.399 0.125 0.044 0.580 0.834

Project Information

  • Owners: JO-ANNE AND JOHN WILSON
  • Address: 49 TOVEY CRESCENT, VICTORIA V9B 1A4
  • Email: JOANNE@THESKYISTHELIMITDESIGN.COM
  • Legal Description: LOT 3 - SECTION 92 - ESQUIMALT DISTRICT PLAN 5895
  • Drawings Included: SITE PLAN W/PROPOSED GARAGE, ELEVATION EXISTING RESIDENCE W/PROPOSED GARAGE
  • Scale: 1:50
  • Calculation: R-VALUE CALCULATION PROPOSED GARAGE
  • Date: AUGUST 15, 2022
  • Designer: THE SKY IS THE LIMIT interior design concepts
  • Designer Address: 780 Humboldt Street Victoria, BC V8W 4A1
  • Designer Contact: 250.882.3156 | info@theskyisthelimitdesign.com
