Community Gardens Layout Plan - Schedule 'B'

October 7, 2014Page 312 sections

Visual site plan showing the proposed expansion phases and existing plots at View Royal Park.

1 CALL TO ORDER
Phases 1 and 1A locations relative to existing parking and picnic areas

Schedule 'B'

Page 31

Layout Plan

Detailed site layout plan showing garden areas, structures, and phases of development.
Detailed site layout plan showing garden areas, structures, and phases of development.

Legend

  • Phase 1
  • Phase 1A
  • Children’s Gardens

Plan Annotations

  • PICNIC AREA
  • POSSIBLE FUTURE FENCE
  • HANDI-CAP ACCESSIBLE AREA (1.50m WIDE)
  • TYPICAL GARDEN BOX 3.05m (10') LONG
  • SHED (Dimensions: 3.00 x 6.00 and 4.00 x 8.00)
  • SLAB
  • Dimensions: 1.00 (TYP.), 1.50 (TYP.)
