Tree Removal & Retention Plan - Eagle's Nest Residences (Sheet L0.01)
A site plan identifying specific trees to be retained, potentially removed, or removed as part of the 3 Helmcken Road development.
Tree Removal & Retention Plan
Project Information
Landscape Architect: Murdoch deGreeff inc. Landscape Planning & Design 200 - 524 Culduthel Road Victoria, BC V8Z 1G1 Phone: 250.412-2891 Fax: 250.412-2892
Client: BOARDWALK DEVELOPMENT 200 - 1501 1 ST. SW CALGARY ALBERTA, T2R 0W1
Project: EAGLES NEST RESIDENCES HELMCKEN & WEST BURNSIDE ROADS VIEW ROYAL, BC
Sheet Title: Tree Removal & Retention Plan Project No.: 121.33 Scale: 1 : 250 @ 24"x36" Drawn by: EB Checked by: SM/JD Sheet No.: L.0.01
Revision Table
| rev no | description | date |
|---|---|---|
| 1 | DP | 2021-10-29 |
Legend
- Property line (Solid black line)
- Right of Way (Dash-dot-dot line)
- Existing Landscape Grade (Red text, e.g., 23.77)
- Architectural grade, provided for reference only (Symbol with black text, e.g., 24.31)
- Proposed Landscape Grade (Black text, e.g., 23.75)
- TW: Top of Wall
- BW: Bottom of Wall
- TOC: Top of Curb
- BC: Bottom of Curb
- TP: Top of Pool
- BP: Bottom of Pool
- TS: Top of Stairs
- BS: Bottom of Stairs
- Existing Tree to be Retained (Green circle)
- Critical Root Zone (CRZ) (Dashed circle)
- Tree Tag # (e.g., #59)
- Existing Tree Potentially Removed (Yellow circle)
- Critical Root Zone (CRZ) (Dashed circle)
- Tree Tag # (e.g., #59)
- Existing Tree to be Removed (Red X)
- Critical Root Zone (CRZ) (Dashed circle)
- Tree Tag # (e.g., #96)
Drawing Notes
- DO NOT SCALE DRAWING: Verify all property lines and existing structures/vegetation to remain, prior to commencing work.
- All plan dimensions in metres and all detail dimensions in millimetres.
- Plant quantities on Plans shall take precedence over plant list quantities.
- Contractor to confirm location and elevation of all existing services and utilities prior to start of construction.
- Provide layout of all work for approval by Landscape Architect prior to proceeding with work.
- Contractor to provide irrigation system for all planters to current IIABC Standards and Contract Specifications.
- Landscape installation to carry a 1 year warranty from date of acceptance.
- Plant material, installation and maintenance to conform to the current edition of the Canadian Landscape Standard.
- General Contractor and/or sub-contractors are responsible for all costs related to production and submission to consultant of all landscape as-built information including irrigation.
- Tree protection fencing, for existing trees, to be installed prior to commencement of all site work.
Site Plan Details
The plan illustrates the development site situated at the corner of Helmcken Road and Burnside Road. Numerous existing trees are identified and tagged across the property and along the adjacent roadways.
Key features include:
- Roads: Helmcken Road (south border) and Burnside Road (east border).
- Tree Identification: Tree tags ranging from #1 to #176, as well as several trees labeled with "NT" tags (NT1 through NT10).
- Tree Status: Trees are marked for retention (green), potential removal (yellow), or confirmed removal (red X) according to the development footprint and landscape requirements.
