Landscape Materials - Eagle's Nest Residences (Sheet L1.01)
A plan detailing the soft and hard landscaping materials, including rain gardens, paving types, and streetscape elements.
Boardwalk Development - Eagles Nest Residences
Project Information
Project: Eagles Nest Residences Location: Helmcken & West Burnside Roads, View Royal, BC Client: Boardwalk Development, 200 - 1501 1 St. SW, Calgary Alberta, T2R 0W1 Landscape Architect: Murdoch de Greeff Inc. Landscape Planning & Design, 200 - 524 Culduthel Road, Victoria, BC V8Z 1G1 Project No: 121.33 Sheet Title: Landscape Materials Sheet No: L1.01 Scale: 1:150 @ 24"x36" Date: 2021-10-29 Drawn by: EB Checked by: SM/JD Revision: 1 DP 2021-10-29
Status: NOT FOR CONSTRUCTION
Reference Notes
- WOONERF STREET AND PATH CONCEPT
- LOBBIES WITH BIKE RACKS AND BENCHES
- ENTRY FEATURES WITH TRELLIS AND BENCHES
- COURTYARD GATHERING AREA
- PARKADE ENTRANCE
- FLEXIBLE PARKING
- RAIN GARDENS
- RETAIN NATIVE TREES AND MANAGEMENT INVASIVES
- ROCK OUTCROP - PRESERVE NATURAL FEATURE OF THE SITE
- SWALES
- STAIRS VARY TO MEET GRADE WITH 3-4 STEPS
Rain Water Management Notes
WATER COLLECTED FROM BUILDING ROOFS FLOW TO THE RAIN GARDENS LOCATED THROUGHOUT THE SITE.
RAIN GARDENS WILL BE DESIGNED WITH UNDERDRAINS AND A HIGH CAPACITY OVERFLOW DRAIN THAT WILL BE CONNECTED TO THE ONSITE PIPED DRAINAGE SYSTEM.
ONSITE HARD SURFACES, WHERE POSSIBLE, WILL BE DRAINED TOWARDS ABSORBENT LANDSCAPE AREAS OR RAIN GARDENS.
STREETSCAPE RAIN GARDENS ARE PROPOSED ON BURNSIDE ROAD. THESE WILL CAPTURE, SLOW AND TREAT (CLEAN) RUNOFF FROM THE MUNICIPAL ROAD AND SIDEWALK MIMICKING THE PRE-DEVELOPMENT DRAINAGE SYSTEM.
Tree Summary
- PROPOSED TREES
- EXISTING TREES
NOTE: RETAINED TREES ARE SUBJECT TO A FULL ARBORICULTURAL ASSESSMENT TO DETERMINE THEIR RETENTION STATUS. EXISTING TREES SHOWN ON THIS PLAN ARE BASED ON PRELIMINARY FIELD OBSERVATIONS AND REVIEW OF THE ARBORIST'S REPORT.
Legend
| Symbol/Text | Description |
|---|---|
| --- --- --- | PROPERTY LINE |
| --- - --- - | EXTENT OF PARKADE (BELOW GRADE) |
| --- . --- . | ROOF LINE |
| ————— | EXISTING CONTOUR LINE |
| 25.20 EX | EXISTING GRADE |
| 28.50 | LANDSCAPE PROPOSED GRADE |
| 28.50 | ARCHITECTURE PROPOSED GRADE |
| (Grey circle) | Rain garden - TOP OF POOL |
| (White circle) | Rain garden - BOTTOM OF POOL |
Underground Utilities
(Shown for reference only - refer to Civil Engineer's drawings)
| Utility | Existing | Proposed |
|---|---|---|
| Storm drain | Dashed Grey Line | Dashed Black Line |
| Sewer | Dashed Grey Line | Dashed Black Line |
| Water | Dashed Grey Line | Dashed Black Line |
| Electrical | Dashed Grey Line | Dashed Black Line |
| Gas | Dashed Grey Line | Dashed Black Line |
| Hydro Tel | Dashed Grey Line | Dashed Black Line |
Abbreviations
- TOW: Top of Wall
- BW: Bottom of Wall
- TOC: Top of Curb
- BC: Bottom of Curb
- TP: Top of Pool
- BP: Bottom of Pool
- TS: Top of Stairs
- BS: Bottom of Stairs
- HP: High Point
- LP: Low Point
Landscape Materials
| Symbol | Description |
|---|---|
| (Solid line with crossbars) | SOLID CEDAR FENCE, 1800 MM HEIGHT, SHOWN OFFSET FROM PROPERTY LINE FOR CLARITY |
| (Vertical dash line) | METAL PICKET FENCE 3' |
| (Double line) | 1070MM METAL MMCD GUARD RAIL |
| (Solid grey block) | CONCRETE RETAINING WALL |
| (Brick pattern block) | LOCK BLOCK RETAINING WALL |
| (White hatching) | WOONERF COURTYARD AREAS CIP CONCRETE - BROOM FINISH - SAWCUT JOINTS 2M x 2M |
| (Grid hatching) | ENTRIES: DECORATIVE, COLOUR, CIP CONCRETE - MAGNESIUM FLOAT FINISH - SAW CUT JOINTS 1M X 1M |
| (Angled hatching) | DRIVEWAY CIP CONCRETE, PEDESTRIAN PATHS SAWCUT @ 3.0 INTERVALS |
| (2x2 grid) | PEDESTRIAN PATH / PATIO - 2 X 2 HYDRASPRESSED SLAB |
| (Solid grey bar) | MUNICIPAL CONCRETE SIDEWALK |
| (Green stipple) | PLANTING AREA 450 MM DEPTH GROWING MEDIUM |
| (Dark green stipple) | MAINTAINED GRASS 150 MM DEPTH GROWING MEDIUM |
| (Light green stipple) | NATURALIZED GRASS |
| (Blue-green stipple) | RAIN GARDEN AREA 450 MM OF RAIN GARDEN GROWING MEDIUM |
| (Dark green solid) | PRESERVED LANDSCAPE ZONE |
| (Grey stipple) | CRUSHED GRAVEL PATH |
Site Furnishings Legend
| Symbol | Description |
|---|---|
| (Vertical parallel lines) | BICYCLE RACK (6 CAPACITY) |
| (Rectangle) | SEATING BENCH |
| (Grid square) | TRELLIS - ENTRY FEATURES |
| (Irregular cloud shape) | BOULDER RETAIN |
| (Solid circle) | BOLLARD |
