EAGLES NEST RESIDENCES - Landscape Materials (Sheet L1.02)
Landscape materials drawing showing woonerf street concept, rain water management notes, and courtyard gathering areas for the development at 3 Helmcken Road.
Landscape Materials - L1.02
Project Information
Project: EAGLES NEST RESIDENCES - HELMCKEN & WEST BURNSIDE ROADS, VIEW ROYAL, BC Client: BOARDWALK DEVELOPMENT, 200 – 1501 1 ST. SW, CALGARY ALBERTA, T2R 0W1 Status: NOT FOR CONSTRUCTION
| rev no | description | date |
|---|---|---|
| 1 | DP | 2021-10-29 |
Project No: 121.33 Scale: 1: 150 @ 24"x36" Drawn by: EB Checked by: SM/JD Sheet No: L1.02 Date: 2021-10-29
[Diagram: Landscape Materials Plan showing proposed layout, grading, planting areas, and site features.]
Legend
- PROPERTY LINE
- EXTENT OF PARKADE (BELOW GRADE)
- ROOF LINE
- EXISTING CONTOUR LINE
- EXISTING GRADE (25.20 EX)
- LANDSCAPE PROPOSED GRADE (28.50)
- ARCHITECTURE PROPOSED GRADE (28.50)
- Rain garden - TOP OF POOL
- Rain garden - BOTTOM OF POOL
Underground Utilities
(Shown for reference only - refer to Civil Engineer's drawings)
| Utility | Existing | Proposed |
|---|---|---|
| Storm drain | Existing | Proposed |
| Sewer | Existing | Proposed |
| Water | Existing | Proposed |
| Electrical | Existing | Proposed |
| Gas | Existing | Proposed |
| Hydro Tel | Existing | Proposed |
- TOW: Top of Wall
- BW: Bottom of Wall
- TOC: Top of Curb
- BC: Bottom of Curb
- TP: Top of Pool
- BP: Bottom of Pool
- TS: Top of Stairs
- BS: Bottom of Stairs
- HP: High Point
- LP: Low Point
Landscape Materials
- SOLID CEDAR FENCE, 1800 MM HEIGHT, SHOWN OFFSET FROM PROPERTY LINE FOR CLARITY
- METAL PICKET FENCE 3'
- 1070MM METAL MMCD GUARD RAIL
- CONCRETE RETAINING WALL
- LOCK BLOCK RETAINING WALL
- WOONERF/ COURTYARD AREAS CIP CONCRETE - BROOM FINISH - SAWCUT JOINTS 2M x 2M
- ENTRIES: DECORATIVE, COLOUR, CIP CONCRETE - MAGNESIUM FLOAT FINISH - SAW CUT JOINTS 1M X 1M
- DRIVEWAY CIP CONCRETE, PEDESTRIAN PATHS SAWCUT @ 3.0 INTERVALS
- PEDESTRIAN PATH / PATIO - 2 X 2 HYDRASPRESSED SLAB
- MUNICIPAL CONCRETE SIDEWALK
- PLANTING AREA - 450 MM DEPTH GROWING MEDIUM
- MAINTAINED GRASS - 150 MM DEPTH GROWING MEDIUM
- NATURALIZED GRASS
- RAIN GARDEN AREA - 450 MM OF RAIN GARDEN GROWING MEDIUM
- PRESERVED LANDSCAPE ZONE
- CRUSHED GRAVEL PATH
Site Furnishings Legend
- BICYCLE RACK (6 CAPACITY)
- SEATING BENCH
- TRELLIS - ENTRY FEATURES
- BOULDER RETAIN
- BOLLARD
Tree Summary
- PROPOSED TREES
- EXISTING TREES
NOTE: RETAINED TREES ARE SUBJECT TO A FULL ARBORICULTURAL ASSESSMENT TO DETERMINE THEIR RETENTION STATUS. EXISTING TREES SHOWN ON THIS PLAN ARE BASED OF PRELIMINARY FIELD OBSERVATIONS AND REVIEW OF THE ARBORISTS REPORT.
Rain Water Management Notes
WATER COLLECTED FROM BUILDING ROOFS FLOW TO THE RAIN GARDENS LOCATED THROUGHOUT THE SITE.
RAIN GARDENS WILL BE DESIGNED WITH UNDERDRAINS AND A HIGH CAPACITY OVERFLOW DRAIN THAT WILL BE CONNECTED TO THE ONSITE PIPED DRAINAGE SYSTEM.
ONSITE HARD SURFACES, WHERE POSSIBLE, WILL BE DRAINED TOWARDS ABSORBENT LANDSCAPE AREAS OR RAIN GARDENS.
STREETSCAPE RAIN GARDENS ARE PROPOSED ON BURNSIDE ROAD. THESE WILL CAPTURE, SLOW AND TREAT (CLEAN) RUNOFF FROM THE MUNICIPAL ROAD AND SIDEWALK MIMICKING THE PRE-DEVELOPMENT DRAINAGE SYSTEM.
Reference Notes
- WOONERF STREET AND PATH CONCEPT
- LOBBIES WITH BIKE RACKS AND BENCHES
- ENTRY FEATURES WITH TRELLIS AND BENCHES
- COURTYARD GATHERING AREA
- PARKADE ENTRANCE
- FLEXIBLE PARKING
- RAIN GARDENS
- RETAIN NATIVE TREES AND MANAGEMENT INVASIVES
- ROCK OUTCROP - PRESERVE NATURAL FEATURE OF THE SITE
- SWALES
- STAIRS VARY TO MEET GRADE WITH 3-4 STEPS
